- Material: Plastic
- Voltage: 14 V DC, 20 V AC, 30 V AC, 30 V DC
- Operating Temp. Range (F): -40 to 150
- Sensor Diameter: 1 mm
- Probe Diameter: 1 in
- Includes Temperature Sensor: Yes
Specifications
| Part Number | HE-69S3-0NP0 |
| Brand | Johnson Controls |
| Material | Plastic |
| Includes | Test and Calibration Equipment Certificate of Calibration Conformance |
| Color | Tan |
| Voltage | 14 V DC, 20 V AC, 30 V AC, 30 V DC |
| Operating Temp. Range (F) | -40 to 150 |
| Height | 2 in |
| Depth | 1 1/2 in |
| Width | 1 1/2 in |
| Sensor Diameter | 1 mm |
| Overall Width | 3 1/4 in |
| Overall Height | 3 1/4 in |
| Overall Depth | 3 5/16 in |
| Cable Length | 10 ft |
| Probe Length | 6 in |
| Overall Length | 8 1/4 in |
| Manufacturers Warranty Length | 3 yr |
| Probe Diameter | 1 in |
| Item | Humidity Sensor |
| Type | Duct |
| For Use With | C450RCN-1C |
| Corrosion Resistant | Yes |
| Includes Temperature Sensor | Yes |
| Maximum Operating Temperature | 140 Degrees F |
| Application | Humidity Monitoring |
| Output Signal | 0 to 5 VDC or 0 to 10 VDC, 1,000 ohm Maximum Load |
| Standards | CCN XAPX, CE Certified, E27734, IEC 60730-2-13, UL 2043, UL Listed, UL 60730-1 |
| Minimum Humidity | 0 % |
| Minimum Operating Temperature | 32 Degrees F |
| Sensor Shape | Square |
| Maximum Humidity | 100 % |
| Maximum Temperature | 140 Degrees F |
| Frequency | 50 Hz, 60 Hz |
| Temperature Accuracy | +/-1.00 Degrees F |
| Humidity Accuracy | +/-3% RH for 20% to 80% RH at 77 Degrees F; +/-5% RH for 10% to 20% and 80% to 90% RH at 77 Degrees F |
| Compatible Manufacturer Model Number | C450RCN-1C |
| Minimum Temperature | 32 Degrees F |
| Temperature Differential | +/-1 Degrees F at 70 Degrees F |
| Indoor/Outdoor | Indoor |
| Compatible Brand and Series | ACC-BRKT-100 - Mounting Bracket, ACC-CBL-100 Wiring Harness, C450RCN-1C Reset Control Modules |
| Electrical Connection Type | Screw Terminals |
| Product Type | Duct Temperature and Humidity Sensor |
| Relative Humidity/Dew Point Output | 0 to 10V DC |
| Minimum Sensing Temperature | -40 Degrees F |
| Features | User-Selectable Output Voltage Range |
| NIST Traceable Certificate | NIST Traceable Certified |
| Housing Material | Plastic |
| Power Required | 12 to 30V DC, 18 to 30V AC |
| Sensing Element Type | Silicon |
| Includes Power Supply | Power Supply Included |
| Housing Color | Blue |
| Loop Resistance | 1,035 ohm |
| Measurement Type | Single |
| RH Sensor | Thermal |
| Display Type | None |
| Relative Humidity Range | 20 to 80% |
| Relative Humidity Accuracy | +/-3% of Full Scale |
| Series | HE-69xx |
| Maximum Sensing Temperature | 212 Degrees F |
| For Use With Building Automation Systems | Building Automation System Compatible |
Description
The Johnson Controls HE-69S3-0NP0 is a duct humidity sensor that measures relative humidity and includes a temperature sensor. It operates on 14 V DC, 20 V AC, 30 V AC, or 30 V DC and is constructed with plastic. This sensor is for use with the C450RCN-1C controller and comes with a Certificate of Calibration Conformance.
