- Temperature Control Range: 55 Degrees to 85 Degrees F
- Air Connection Outside Diameter: 1/4 in
- Temperature Settings: Single Temperature
- Control Air Pressure Settings: 16 psig (Summer)/ 25 psig (Winter)
- Temperature Scale: Celsius/Fahrenheit
- Minimum Control Temperature: 55 Degrees F
Specifications
| Part Number | 2218-133 |
| Brand | Schneider Electric |
| Fits Brand | Schneider Electric |
| Application | Heat and Cool |
| Includes | 20-693 Tubing, 20-711 Mounting Plate, 20-714 Wall Plate, Mounting Hardware |
| Temperature Control Range | 55 Degrees to 85 Degrees F |
| Mounting Direction/Includes Cover | Horizontal/Vertical, Yes |
| Overall Height | 2 1/16 in |
| Air Connection Outside Diameter | 1/4 in |
| Overall Width | 2 1/16 in |
| Overall Depth | 1 3/8 in |
| Item | Pneumatic Thermostat |
| Thermostat Action | Direct - 16 psig, Reverse - 25 psig |
| Number of Pipes/Air Flow Output | 2 Pipes, High Volume |
| Temperature Settings | Single Temperature |
| Control Air Pressure Settings | 16 psig (Summer)/ 25 psig (Winter) |
| Differential Type | Adjustable |
| Temperature Scale | Celsius/Fahrenheit |
| Mounting Direction | Horizontal, Vertical |
| Minimum Control Temperature | 55 Degrees F |
| Sensor Type | Bi-Metallic Spring |
| Pneumatic Thermostat Type/Indexing Switch | Summer/Winter |
| Number of Dials | Dual |
| Operating Humidity Range | 5% to 95% RH |
| Action | Direct and Reverse |
| Throttling Range | 2 Degrees to 12 Degrees F |
| Control Type | Exposed Dial |
| Cover Color | Gray |
| Number of Pipes | 2 |
| Pneumatic Thermostat Type | Summer/Winter |
| Air Consumption | 29.4 scim (15 psig); 34.5 scim (20 psig) |
| Air Flow Output | High Volume |
| Manual Indexing Switch | No |
| Maximum Control Temperature | 85 Degrees F |
| Fitting Connection | Barbed 3/16 in |
| Compatible System Type | Pneumatic Valves and Damper Actuators |
| Maximum Air Pressure | 30 psig |
Description
The Schneider Electric 2218-133 is a pneumatic thermostat for heat and cool applications. This type of thermostat uses compressed air to control the temperature, operating with two pipes and a high-volume air flow output. It features a single temperature setting with control air pressure settings of 16 psig for summer and 25 psig for winter, and includes the 20-693 tubing, 20-711 mounting plate, 20-714 wall plate, and mounting hardware.
