- Body Material: Brass
- Voltage: 24
- Connection Type/Size: Sweat 1
- Port Connection Size: 1 in
- Max. Water Temp. (Deg. F): 220 Degrees F
- Actuator Housing Material: Polymer
Specifications
| Part Number | Z100C3-2 |
| Brand | Taco |
| Body Material | Brass |
| Voltage | 24 |
| For Use With | Closed Systems |
| Includes | End Switch |
| Coefficient of Volume | 4.5 |
| Height | 5 1/8 in |
| Width | 5 5/16 in |
| Connection Type/Size | Sweat 1 |
| Depth | 2 3/8 in |
| Port Connection Size | 1 in |
| Overall Length | 5 1/2 in |
| Overall Depth | 2 3/8 in |
| Overall Width | 5 5/16 in |
| Item | Motorized Zone Valve |
| Electrical Connections | 2-Pin Screw Connectors for Power and End Switch |
| Max. Water Temp. (Deg. F) | 220 Degrees F |
| Safe Working Water PSI | 300 psi |
| Type | Three Way, Closed System |
| Actuator Housing Material | Polymer |
| Fluid Temperature - Maximum | 220 Degrees F |
| Actuator Control Signal | On/Off |
| Application | Air Handlers, Baseboard Heaters, Convectors, Fan Coils, Heat Pumps, Radiators |
| Actuator Return Action | Double Acting |
| Valve Action | Normally Closed |
| Allowable Pressure - Maximum | 300 psi |
| Fluid Temperature - Minimum | 20 Degrees F |
| Actuator Type | Electric |
| Actuator Voltage | 24V AC |
| Close-Off Pressure | 125 psi |
| Gasket/Plug Material | EPDM |
| Port Connection Type | Sweat |
| Operating Temperature - Maximum | 135 Degrees F |
| Actuator Gears Material | Polymer |
| Stem Material | Brass |
| Frequency | 60 Hz |
| Valve Type | Ball |
| Installation Orientation | Versatile |
| Body Pattern | Three-Way |
| Includes Actuator | Actuator Included |
| Coefficient of Volume (Cv) | 8.9 |
| Bypass Port Coefficient of Volume (Cv) | 3 |
| Port Connection Gender | Female |
| Standards | NSF Certified |
| For Media | Water, Water-Glycol Solution to 50% |
| Spring Action | Non-Spring Return |
| Distance Between Inlet and Outlet Port | 3 7/8 in |
Description
The Taco Z100C3-2 is a 24-volt motorized zone valve with a 3.0 Cv flow coefficient, constructed with a brass body and a 1-inch sweat connection. This three-way valve is designed for use in closed systems, controlling flow by opening and closing in response to a thermostat signal. It includes an end switch and features 2-pin screw connectors for power and end switch wiring.
