- Amps AC: 10.00 to 16.00A
- Frame Size: D
- HP @ 3 Phase - 240V: 5 hp
- Size: 55 mm
- HP @ 3 Phase - 480V: 10 hp
- Max. Voltage: 600V AC
Specifications
| Part Number | XTPR016DC1 |
| Brand | Eaton |
| Amps AC | 10.00 to 16.00A |
| Frame Size | D |
| Operator | Selector Switch |
| Width | 2.17 in |
| HP @ 3 Phase - 240V | 5 hp |
| Height | 5.57 in |
| Depth | 6.73 in |
| Product Width | 6.5 in |
| Size | 55 mm |
| Product Height | 6 in |
| Product Length/Depth | 2.5 in |
| Overall Height | 6 in |
| Overall Depth | 2.5 in |
| Overall Width | 6.5 in |
| Item | Manual Motor Protector |
| HP @ 3 Phase - 480V | 10 hp |
| Max. Voltage | 600V AC |
| Number of Poles | 3 |
| HP @ 3 Phase - 575V | 15 hp |
| Standards | ATEX Compliant, CE, CSA, UL 508 Group Motor Type E Compliant, UL Listed |
| HP @ 3 Phase - 200V | 3 hp |
| HP @ 1 Phase - 115V | 1 hp |
| HP @ 1 Phase - 230V | 3 hp |
| Starter Type | Manual |
| Weight | 2.5 lb |
| Trip Class | Class 10 |
| Phase Loss Sensitivity | Yes |
| Type | Rotary |
| Amperage Rating | 16A |
| Product Name | Eaton XT IEC motor control |
| Certifications | UL 508;CSA Std. C22.2 |
| Terminal Connection Type | Screw Terminals |
| Mounting Style | DIN Rail |
| Horsepower @ Single Phase - 120V AC | 1 hp |
| NEMA Enclosure Rating | No Enclosure |
| Horsepower @ Three Phase - 240V AC | 5 hp |
| Minimum Overload Relay Current Setting | 10 A |
| Starter Style | IEC |
| Includes Pilot Light | No |
| Maximum Overload Relay Current Setting | 16 A |
| Horsepower @ Three Phase - 600V AC | 15 hp |
| Series | XTPR Series |
| Horsepower @ Single Phase - 240V AC | 3 hp |
| Horsepower @ Three Phase - 480V AC | 10 hp |
| Horsepower @ Three Phase - 208V AC | 3 hp |
| Overload Protection Type | Thermal |
| Current AC | 16 A |
| Maximum Voltage Rating | 600V AC |
| Phase | Three |
Description
The Eaton XTPR016DC1 is a manual motor protector rated for 10.00 to 16.00A. This type of part provides overload and short-circuit protection for a motor by manually switching the circuit on and off. It is compliant with ATEX, CE, CSA, and UL 508 Group Motor Type E standards, and is UL Listed for use at a maximum voltage of 600V AC.
