- Voltage: 100 to 240V AC
- Ambient Temp. Range: -22 Degrees to 140 Degrees F
- Control Signal: On/Off
- Operating Temperature - Maximum: 140 Degrees F
- Housing Material: Plastic
- Frequency: 50/60 Hz
Specifications
| Part Number | VA9203-BUA-2 |
| Brand | Johnson Controls |
| Voltage | 100 to 240V AC |
| Signal Type | On-Off |
| Torque | 27 in-lb |
| Cycle Time | 71 sec |
| Ambient Temp. Range | -22 Degrees to 140 Degrees F |
| Width | 3 5/16 in |
| Height | 3 13/32 in |
| Depth | 4 13/16 in |
| Overall Width | 3 5/16 in |
| Stroke Length | Not Rated |
| Overall Depth | 4 13/16 in |
| Overall Height | 3 7/16 in |
| Electrical Lead Length | 4 ft |
| Item | Electric Ball Valve Actuator |
| For Use With | JCI VG1000 Ball Valve |
| Mounting | Direct Mount |
| Includes | Valve Linkage |
| Ball Valve Product Group | Actuated |
| Standards | CCN XAPX File E27734, CE, UL Listed |
| Auxiliary Switch Type | SPDT |
| Power Consumption | 7.2 VA |
| Enclosure Rating | NEMA 2 |
| Stroke Deg. | 95 |
| Electrical Connections | Cable |
| Type of Actuator | Spring Return |
| Product Type | Electric Ball Valve Actuator |
| Control Signal | On/Off |
| Includes Electrical Leads | Electrical Leads Included |
| Electrical Connection Type | Cable |
| Operating Temperature - Maximum | 140 Degrees F |
| Mounting Style | Direct Mount |
| Compatible Valve Action | Normally Closed, Normally Open |
| Compatible Valve Body Pattern | Three-Way, Two-Way |
| Housing Material | Plastic |
| Compatible Manufacturer Model Number | VG1241AD+923BUA, VG1241AE+923BUA, VG1241AF+923BUA, VG1241AG+923BUA, VG1241AL+923BUA, VG1241AN+923BUA, VG1241BG+923BUA, VG1241BL+923BUA, VG1241BN+923BUA, VG1241CL+923BUA, VG1241CN+923BUA, VG1241CP+923BUA |
| Frequency | 50/60 Hz |
| Compatible Brand | Johnson Controls |
| Stroke Degree | 95 Degrees |
| Return Action | Spring Return |
| Operating Temperature - Minimum | -22 Degrees F |
| Number of Auxiliary Switches | 0 |
| Auxiliary Contact Form | SPDT |
| Application | Air Conditioning, Heating, Ventilation |
| Compatible Series | VG1000 |
| NEMA Rating | 2 |
Description
The Johnson Controls VA9203-BUA-2 is an electric ball valve actuator. This on-off actuator opens or closes a valve in response to a control signal, operating on 100 to 240V AC. It is for use with the JCI VG1000 Ball Valve and includes the valve linkage. The actuator is UL Listed and CE certified under CCN XAPX File E27734.
