- Voltage: 24V AC
- Ambient Temp. Range: To 140 Degrees F
- Control Signal: On/Off
- Operating Temperature - Maximum: 140 Degrees F
- NEMA Rating: 2
- Operating Temperature - Minimum: -22 Degrees F
Specifications
| Part Number | VA9203-BGB-2 |
| Brand | Johnson Controls |
| Voltage | 24V AC |
| Signal Type | On-Off |
| Torque | 27 in-lb |
| Cycle Time | 75 sec |
| Ambient Temp. Range | To 140 Degrees F |
| Height | 6 3/8 in |
| Width | 3 1/4 in |
| Depth | 2 3/4 in |
| Overall Width | 3 1/4 in |
| Overall Depth | 2 3/4 in |
| Stroke Length | Not Rated |
| Overall Height | 6 3/8 in |
| Electrical Lead Length | 4 ft |
| Item | Electric Ball Valve Actuator |
| Power Consumption | 5 VA |
| For Use With | VG 1000 Ball Valves |
| Electrical Connections | Cable |
| Stroke Deg. | 90 |
| Ball Valve Product Group | Actuated |
| Type of Actuator | Spring Return |
| Auxiliary Switch Type | 1 SPDT |
| Includes | Valve Linkage |
| Standards | C-Tick, CCN XAPX7, CE, CSA C22.2 No. 24-93, UL Listed, UL 60730-1:02-CAN/CSA |
| Product Type | Electric Ball Valve Actuator |
| Compatible Series | VG1000 |
| Control Signal | On/Off |
| Operating Temperature - Maximum | 140 Degrees F |
| Number of Auxiliary Switches | 1 |
| NEMA Rating | 2 |
| Operating Temperature - Minimum | -22 Degrees F |
| Mounting Style | Direct Mount |
| Return Action | Spring Return |
| Application | Air Conditioning, Heating, Ventilation |
| Frequency | 50/60 Hz |
| Electrical Connection Type | Cable |
| Compatible Brand | Johnson Controls |
| Stroke Degree | 95 Degrees |
| Auxiliary Contact Form | SPDT |
| Includes Electrical Leads | Electrical Leads Included |
| Power Rating | 6VA |
| Shaft Type | Integrated Shaft for Valve |
Description
The Johnson Controls VA9203-BGB-2 is a 24V AC electric ball valve actuator with spring return and on-off signal control. This type of actuator opens and closes a ball valve to regulate flow, and it is used with VG 1000 ball valves. The actuator includes one SPDT auxiliary switch and operates in ambient temperatures up to 140 degrees Fahrenheit.
