- Max. Water Temp. (Deg. F): 36 to 248
- Connection Type/Size: (F)NPT 3/4
- Pipe Size: 3/4"
- Port Connection Size: 3/4 in
- Body Material: Brass
- Stem Material: Stainless Steel
Specifications
| Part Number | V5011N1057 |
| Brand | Honeywell |
| For Use With | Water or Glycol Solution 50% Max |
| Width | 3 1/4 in |
| Max. Water Temp. (Deg. F) | 36 to 248 |
| Depth | 1 9/16 in |
| Type | 2-Way, Direct Acting |
| Height | 6 5/8 in |
| Connection Type/Size | (F)NPT 3/4 |
| Overall Height | 6 5/8 in |
| Overall Length | 3 1/4 in |
| Pipe Size | 3/4" |
| Port Connection Size | 3/4 in |
| Overall Depth | 1 9/16 in |
| Item | Hydronic Globe Valve |
| Description/Special Features | Valve Designs Provide Equal Percentage Characteristics Of Flow For Close Control Of Water, And Linear Characteristic Of Flow For Close Control Of Steam. |
| Coefficient of Volume | 7.3 |
| Includes | Installation Manual |
| Safe Working Steam PSI | 40.5 |
| Safe Working Water PSI | 240 |
| Agency Compliance | CRN |
| Specifications | Spring Loaded, Self-Adjusting Packing. Stainless Steel Stem Prevents Corrosion. Valve Design Provides Equal Percentage Characteristics Of Flow For Close Control Of Water, And Linear Characteristics Of Flow For Close Control Of Steam. |
| Body Material | Brass |
| Connection Type | Two-Way |
| Stem Material | Stainless Steel |
| Seat Material | Stainless Steel |
| Operating Temperature - Maximum | 337 Degrees F |
| Port Connection Type | NPT |
| Body Pattern | Two-Way |
| Rangeability | 50:1 |
| For Media | Steam, Water |
| Configuration | Straight-Thru |
| Coefficient of Volume (Cv) | 7.3 |
| Port Connection Gender | Female |
| Valve Action | Normally Closed, Normally Open |
| Trim Material | Brass |
| Installation Orientation | Vertical |
| Specific Valve Action | Stem Down to Close |
| Leakage Rate | 0.05% |
| Close-Off Pressure | 230 psi |
| Flow Characteristic | Equal Percentage |
| Packing Material | PTFE |
| ANSI Rating | ANSI Class 150 |
| Includes Actuator | Actuator Not Included |
| Operating Temperature - Minimum | 36 Degrees F |
| Manufacturer Series | V5011N |
Description
The Honeywell V5011N1057 is a hydronic globe valve, specifically a 2-way, direct-acting valve. This type of valve modulates flow to provide close control, with equal percentage characteristics for water and linear characteristics for steam. It is designed for use with water or glycol solution up to 50% max, within a temperature range of 36 to 248 degrees Fahrenheit.
