- Voltage: 24VAC
- Display Size: 4 sq in
- Digit Size: Easy Read
- Temporary Program Override: Yes
- Temporary Temperature Hold: Yes
- Temp. Settings per Day: 4
Specifications
| Part Number | T725 |
| Brand | Pro1 Iaq |
| Voltage | 24VAC |
| Stages Heat | 2 |
| Mounting Type | Horizontal or Vertical |
| Mounting Location | Wall |
| Color | White |
| Height | 4 13/32" |
| Width | 4 45/64" |
| Depth | 1 7/64 in |
| Display Size | 4 sq in |
| Screen Width | 4 in |
| Screen Height | 4 in |
| Overall Height | 4 3/8 in |
| Overall Width | 4 11/16 in |
| Digit Size | Easy Read |
| Overall Depth | 1 1/8 in |
| Item | Heat Pump / Conventional |
| Control Range | 44 Degrees to 90 Degrees F |
| System Switching | Heat-Cool-Off-Emergency |
| Stages Cool | 1 |
| Dual Transformer Compatible | No |
| Power Method | Hardwired/Battery |
| 750mV Compatible | No |
| Programs per Week | 5-1-1 |
| WiFi Capability | No |
| Battery Backup | Yes |
| Temporary Program Override | Yes |
| Dehumidification Control | No |
| Low Battery Indicator | YES |
| Temporary Temperature Hold | Yes |
| Includes | Manual/Install Guide, Mounting Hardware |
| Features | Programmable Heat Pump |
| Remote Sensing Capability | No |
| Humidification Control | No |
| Temp. Settings per Day | 4 |
| Temperature Limiting | Yes |
| For Use With | Heating and Cooling |
| Key Pad Lockout | No |
| Automatic Changeover | No |
| Fan Switching | Auto-On |
| Filter Indicator | Yes |
| Display Color | Blue |
| Batteries Included | Yes |
| Display Type | Backlit |
| Terminal Designations | B, C, E, G, O, R, W2, Y |
| Programmable Fan | No |
| Control Type | Push Button |
| Stages | 1H/1C Conventional, 2H/1C Heat Pump |
| Temperature Control Range | 44 Degrees to 90 Degrees F |
| Thermostat Type | Low Voltage |
| Differential Type | Adjustable |
| Temperature Sensitivity | +/-1 Degrees F |
| Number of Heating Stages - Conventional System | 1 |
| Mounting Direction/Shape | Square |
| Operating Temperature Range | 32 Degrees to 105 Degrees F |
| Backlit Screen Color | Blue |
| Temperature Scale | Fahrenheit/Celsius |
| Includes Batteries | Yes |
| Minimum Control Temperature | 44 Degrees F |
| Shape | Square |
| Smart Connectivity | No Connectivity |
| Application/Stages | Heat and Cool; 1H/1C Conventional, 2H/1C Heat Pump |
| Maximum Control Temperature | 90 Degrees F |
| Number of Cooling Stages - Conventional System | 1 |
| Backlit Screen | Yes |
| Battery Type | (2) AA Batteries |
| Programming Capability | 5-1-1, 7 Day |
| Temperature Differential | 0.2 Degrees to 2.0 Degrees F |
| Number of Cooling Stages - Heat Pump System | 1 |
| Number of Heating Stages - Heat Pump System | 2 |
| Includes Positive Off | Yes |
| Filter Change Reminder | Yes |
| Temperature Readout | Yes |
| Minimum Operating Temperature | 32 Degrees F |
| System/Fan Settings | Cool-Emergency Heat-Heat-Off/Auto-On |
| Temperature settings per day | 4 |
| Maximum Operating Temperature | 105 Degrees F |
| Changeover Type | Manual |
| Electrical Connection Type | Hardwired |
| Millivolt Compatible | No |
| Compatible System Type | Electric Forced Air Furnaces, Gas Forced Air Furnaces, Heat Pump with Aux, Heat Pump without Aux, Millivolt |
| Application | Heat and Cool |
| Differential Heat | 0.2 Degrees F, 2 Degrees F |
| Fan Settings | Auto-On |
| Housing Color | White |
| Maximum Operating Humidity | 90 % |
| System Settings | Cool-Emergency Heat-Heat-Off |
| Frequency | 50 Hz, 60 Hz |
| Mounting Direction | Horizontal; Vertical |
| Differential Cool | 0.2 Degrees F, 2 Degrees F |
Description
The Pro1 Iaq T725 is a 24VAC condensate pump designed for heat pump or conventional systems. This type of pump removes accumulated condensate from HVAC equipment. It can be mounted horizontally or vertically and includes a manual/install guide and mounting hardware.
