- Amps AC: 1 Pilot, 2 Main
- Voltage: 24
- Control Voltage: 24V AC
- Frequency: 60 Hz
- Maximum Operating Temperature: 165 Degrees F
- Input Voltage: 24V AC
Specifications
| Part Number | S8610U3009 |
| Brand | Resideo |
| Depth | 2 5/8 in |
| Amps AC | 1 Pilot, 2 Main |
| Type | Intermittent Pilot Ignition |
| Bracket | Universal |
| Includes | Damper Connection with Automatic Vent Damper Plug |
| Height | 3 15/16 in |
| Width | 5 7/16 in |
| Item | Intermittent Pilot Ignitor |
| Lockout Time (Sec.) | 15 Or 90 |
| For Use With | Residential, Commercial Heating Equipment With Single Rod Or Dual Rod Remote Sense Applications |
| Electrical Connections | 1/4 in Spade Terminals And Molex Plugs |
| Electrical Ratings | 24V AC |
| Voltage | 24 |
| Operation Description | One Or Two Rod Intermittent Pilot Control With Continuous Retry Trial Time With Configurable Lockout Timing Of 15 Or 90 Seconds And Configurable Prepurge Of 30 seconds or no prepurge |
| Prepurge Time (Sec.) | Up to 30 |
| Control Volts | 24 V |
| Retries | Continuous |
| Gas Type | LP/NG |
| Application | Remote Sensing, Single Rod/Dual Rod |
| Product Type | Intermittent Pilot Ignitor |
| Thermostat Anticipator Setting | Thermostat Anticipator |
| Control Voltage | 24V AC |
| Pre-Purge Time | 30 sec |
| Automatic Reset Time | 5 min |
| For Fuel Type | LP, Natural Gas |
| Lock Out Time | 15 sec |
| Ignition Cycle Time | 90 seconds (Spark) |
| Compatible with Brand | Camstat, Fenwal, Honewell, HSC, Penn-Johnson, Robertshaw |
| Number of Retries | 3 |
| Replacement Type | Universal |
| Frequency | 60 Hz |
| Maximum Operating Temperature | 165 Degrees F |
| Input Voltage | 24V AC |
| Minimum Operating Temperature | -40 Degrees F |
| Main Valve Current Output | 24 A |
| Flame Sensor Current Output | 1 uA |
Description
The Resideo S8610U3009 is an intermittent pilot ignition module for use with residential and commercial heating equipment in single-rod or dual-rod remote sense applications. This control board operates on 24V AC with electrical ratings of 1 pilot and 2 main amps AC, and includes a damper connection with an automatic vent damper plug. It features 1/4-inch spade terminals and Molex plugs for electrical connections.
