- Body Material: Cast Iron
- Gasket/Plug Material: CrNi Steel
- Port Connection Size: 3/4 in
- Operating Temperature - Maximum: 113 Degrees F
- Fluid Temperature - Maximum: 266 Degrees F
- Stem Material: Brass
Specifications
| Part Number | MXG461.20-5.0U |
| Brand | Siemens |
| Body Material | Cast Iron |
| Gasket/Plug Material | CrNi Steel |
| Overall Length | 12 in |
| Overall Depth | 3 in |
| Includes Actuator | Actuator Included |
| Port Connection Size | 3/4 in |
| Overall Width | 3 in |
| Item | Magnetic Valve |
| Operating Temperature - Maximum | 113 Degrees F |
| Fluid Temperature - Maximum | 266 Degrees F |
| Stem Material | Brass |
| Close-Off Pressure | 44 psi |
| Port Connection Type | Union NPT |
| Coefficient of Volume (Cv) | 5.9 |
| Fluid Temperature - Minimum | 34 Degrees F |
| Frequency | 50/60 Hz |
| Product Type | Control Valve Assembly |
| Body Pattern | Two-Way |
| Actuator Type | Magnetic |
| Application | Chilled/Hot Water Control |
| Installation Orientation | Vertical Preferred |
| Standards | cUL, UL Listed |
| Spring Action | Spring Return |
| Valve Action | Normally Closed |
| For Media | Water, Water-Glycol Solution to 50% |
| Actuator Control Signal | Floating |
| Actuator Voltage | 24V AC/DC |
| Distance Between Inlet and Outlet Port | 3 3/4 in |
| Actuator Return Action | Spring Return |
Description
The Siemens MXG461.20-5.0U is a magnetic hydronic zone valve with an integrated actuator. This valve controls fluid flow in a hydronic system, using a magnetic coil to open and close the valve body, which is constructed from cast iron with a CrNi steel gasket/plug and a brass stem. It has a 3/4-inch port connection and a flow coefficient (Cv) of 5.9, with a maximum operating temperature of 113°F and a maximum fluid temperature of 266°F.
