- Voltage: 24V AC/DC
- For Shaft Diameter: 5/8 in
- Ambient Temp. Range: -22 Degrees to 131 Degrees F
- Minimum Operating Temperature: -22 Degrees F
- NEMA Rating: 2
- Maximum Operating Temperature: 131 Degrees F
Specifications
| Part Number | MEP-4001 |
| Brand | Kmc Controls |
| Mounting Type | Direct Mount |
| Spring Return | Non-Spring Return |
| Signal Type | Floating Point |
| Torque | 40 in-lb |
| Voltage | 24V AC/DC |
| Depth | 5 3/8 in |
| Height | 2 1/2 in |
| Width | 2 5/8 in |
| Overall Depth | 5 1/4 in |
| Overall Height | 2 1/2 in |
| For Shaft Width | 1/2 in |
| For Shaft Height | 1/2 in |
| For Shaft Diameter | 5/8 in |
| Overall Width | 2 5/8 in |
| Type | Non-Spring Return |
| Ambient Temp. Range | -22 Degrees to 131 Degrees F |
| Includes | Non-Rotation Bracket |
| Motor Direction | CW or CCW |
| Item | Actuator |
| For Use With | Dampers or Valves that Require Up to 40 in-lb of Torque |
| Shaft Type | 1/4 in to 5/8 in Round or 1/4 in to 7/16 in Square |
| Electrical Connections | 22-14 AWG Wire Clamp |
| Power Consumption | 4 VA |
| Stroke Deg. | 0 to 95 |
| Timing | 90 sec |
| Minimum Operating Temperature | -22 Degrees F |
| Contact Form | SPDT |
| NEMA Rating | 2 |
| Maximum Operating Temperature | 131 Degrees F |
| Shaft Rotation | CW/CCW |
| Rated Torque | 40 in-lb |
| Number of Auxiliary Switches | 0 |
| Input Voltage | 24V AC |
| IP Rating | IP54 |
| Electrical Connection Type | Hardwired |
| Time to Close | 90 sec |
| For Use With Building Automation Systems | Building Automation System Compatible |
| Standards | CE Certified, Complies with Canadian ICES-003, FCC Class B, Part 15, Subpart B, UL 873 |
| For Shaft Shape | Round, Square |
| Housing Material | Polymer |
| Stroke Degree | 0 to 95 Degrees |
| Compatible with Series | BC, BX, VFB-43, VFB-46 |
| Valve Application | Damper and Valve |
| Product Type | Actuator |
| Weight | 1.1 lb |
| Application | Dampers, Valves, VAV Boxes |
Description
The Kmc Controls MEP-4001 is a 24V AC/DC electric actuator with a floating point (tri-state) signal and non-spring return design. As an actuator, it opens and closes dampers or valves based on control signals. It is for use with dampers or valves that require up to 40 in-lb of torque and includes a non-rotation bracket.
