- Voltage: 24V AC
- Ambient Temp. Range: -40 Degrees to 150 Degrees F
- Input Voltage: 24V AC
- Housing Material: Aluminum
- NEMA Rating: 3
- Minimum Operating Temperature: -40 Degrees F
Specifications
| Part Number | M8185D1006 |
| Brand | Honeywell |
| Signal Type | On/Off |
| Torque | 60 in-lb |
| Voltage | 24V AC |
| Type | Spring-Return |
| Width | 5 1/2 in |
| Height | 6 7/16 in |
| Depth | 8 3/4 in |
| Overall Width | 5 1/2 in |
| Overall Height | 6 1/2 in |
| For Shaft Width | 3/8 in |
| Overall Depth | 8 3/4 in |
| For Shaft Height | 3/8 in |
| Switch Type | SPST |
| Item | Rotary Actuator |
| Stroke Deg. | 160 |
| For Use With | Two Wire Thermostats or Other SPST Controllers |
| Power Rating | 20W |
| Motor Direction | CW |
| Includes | Wiring Box |
| Timing | 30 to 60 sec Nominal @ 60 Hz |
| Replaces Honeywell Motors | Mfr. No. M845A, Mfr. No. M845C, Mfr. No. M845D, Mfr. No. M865B, Mfr. No. M865E |
| Ambient Temp. Range | -40 Degrees to 150 Degrees F |
| Shaft Type | Double-Ended |
| Power Consumption | 20 VA |
| Electrical Connections | Quick-Connect Terminals |
| Input Voltage | 24V AC |
| Housing Material | Aluminum |
| Application | Dampers, Valves |
| Standards | Guide No. XAPX for USA and Canada, UL Listed E4436 |
| Electrical Connection Type | Hardwired |
| NEMA Rating | 3 |
| Product Type | Rotary Actuator |
| Shaft Rotation | CW |
| Minimum Operating Temperature | -40 Degrees F |
| IP Rating | IP54 |
| For Use With Building Automation Systems | Building Automation System Compatible |
| Valve Application | Damper and Valve |
| Contact Form | SPST |
| For Shaft Shape | Square |
| Stroke Degree | 160 Degrees |
| Time to Close | 60 sec |
| Maximum Operating Temperature | 150 Degrees F |
| Number of Auxiliary Switches | 0 |
| Rated Torque | 60 in-lb |
Description
The Honeywell M8185D1006 is a 24V AC spring-return rotary actuator with an SPST switch type. This electric actuator provides on/off control and is used with two-wire thermostats or other SPST controllers. It has a power rating of 20W and includes a wiring box.
