- Voltage: 24V AC
- Ambient Temp. Range: -40 Degrees to 140 Degrees F
- Maximum Operating Temperature: 140 Degrees F
- Input Voltage: 24V AC
- Minimum Operating Temperature: -40 Degrees F
- NEMA Rating: 3
Specifications
| Part Number | M6184D1035 |
| Brand | Honeywell |
| Mounting Type | Remote Mount |
| Spring Return | Non-Spring Return |
| Signal Type | Floating Point |
| Torque | 150 in-lb |
| Voltage | 24V AC |
| Depth | 7 5/16 in |
| Height | 6 7/16 in |
| Width | 5 1/2 in |
| Overall Depth | 7 3/8 in |
| For Shaft Height | 3/8 in |
| Overall Width | 5 1/2 in |
| Overall Height | 6 1/2 in |
| For Shaft Width | 3/8 in |
| Type | Non-Spring Return |
| Timing | 30 to 60 sec |
| Item | Actuator |
| Motor Direction | CW or CCW |
| Switch Type | SPDT |
| Replaces Honeywell Motors | Mfr. No. M644A-E |
| Shaft Type | Double-Ended |
| Power Consumption | 17 VA |
| Includes | Wiring Box |
| Ambient Temp. Range | -40 Degrees to 140 Degrees F |
| Stroke Deg. | 90 to 160 |
| Electrical Connections | Quick-connect Terminals |
| Time to Close | 60 sec |
| Standards | NEMA 3 wiring box, UL Listed and CSA Certified |
| Product Type | Actuator |
| For Shaft Shape | Square |
| Electrical Connection Type | Hardwired |
| Maximum Operating Temperature | 140 Degrees F |
| Shaft Rotation | CW/CCW |
| Valve Application | Damper and Valve |
| Stroke Degree | 90 to 160 Degrees |
| Contact Form | SPDT |
| Input Voltage | 24V AC |
| Rated Torque | 150 in-lb |
| Number of Auxiliary Switches | 0 |
| Minimum Operating Temperature | -40 Degrees F |
| NEMA Rating | 3 |
| Application | Dampers |
Description
The Honeywell M6184D1035 is a 24V AC, non-spring return electric actuator with a floating point signal and SPDT switch type. This actuator provides 150 in.-lb. of torque to open and close valves or dampers, and it features a double-ended shaft and remote mount configuration. The unit includes a wiring box.
