- Coil Voltage: 120V AC
- HP @ 1 Phase - 230V: 1-1/2
- HP @ 3 Phase - 575V: 10 hp
- Enclosure NEMA Rating: No Enclosure
- Overvoltage Category: CAT III
- Rated Making Capacity: 110 A (AC Signalling Circuit), 144 A (AC Power Circuit)
Specifications
| Part Number | LC1K1210G7 |
| Brand | Square D |
| Auxiliary Contact Form | 1NO |
| Coil Voltage | 120V AC |
| Number of Poles | 3 |
| Reversing Capability | Non-Reversing |
| Terminal Connection Type | Screw Clamp |
| Working Height | 6561.68 ft |
| Overall Height | 2.28 in |
| Overall Width | 1.77 in |
| Overall Depth | 2.24 in |
| Item | IEC Miniature Magnetic Contactor |
| Number of Auxillary Contacts | 1 |
| Standards | BS 5424, CSA, IEC 60947, NF C 63-110, UKCA, UL Listed, VDE 0660 |
| Reversing | No |
| HP @ 1 Phase - 230V | 1-1/2 |
| Frame / Series / Class / Code | TeSys |
| HP @ 3 Phase - 575V | 10 hp |
| Enclosure NEMA Rating | No Enclosure |
| Series | TeSys K |
| Application | Motor Control, Resistive Load |
| Environmental Attributes | Mercury Free, Toxic Heavy Metal Free |
| Mechanical Durability | 10 Mcycles |
| Inrush VA | 30 VA |
| Overvoltage Category | CAT III |
| IP Rating | IP22 |
| Net Weight | 0.18 kg |
| Impedance | 3 mOhm |
| Tightening Torque | 0.8 to 1.3 Nm |
| Rated Making Capacity | 110 A (AC Signalling Circuit), 144 A (AC Power Circuit) |
| Electrical Durability | 0.3 Mcycles (20 A, AC-1, Less than 440 V); 1.3 Mcycles (12 A, AC-3, Less than 440 V); 1.3 Mcycles (12 A, AC-3e, Less than 440 V) |
| Switching Voltage | 17 V (Signalling Circuit) |
| Vibration Resistance | 4 G (Contactor Closed), 2 G (Contactor Open) |
| Control Circuit Voltage Limits | Operational: 0.8 to 1.15 Uc (at 50°C), Drop-Out: 0.2 to 0.75 Uc (at 50°C) |
| Shock Resistance | 10 G for 11 ms (on X axis with Contactor Closed), 15 G for 11 ms (on Y and Z axis with Contactor Closed), 6 G for 11 ms (on X axis with Contactor Open), 10 G for 11 ms (on Y and Z axis with Contactor Open) |
| Rated Short-Time Withstand Current | 115 A (at 50°C for 1 s Power Circuit), 105 A (at 50°C for 5 s Power Circuit), 100 A (at 50°C for 10 s Power Circuit), 75 A (at 50°C for 30 s Power Circuit), 55 A (at 50°C for 1 min Power Circuit), 50 A (at 50°C for 3 min Power Circuit), 80 A (For 1 s Signalling Circuit), 90 A (For 500 ms Signalling Circuit), 110 A (For 100 ms Signalling Circuit), 25 A (at 50°C for 15 min Power Circuit) |
| Fire Rating | UL 94 V1, NF F 16-101, NF F 16-102 |
| Fuse Amps | 25 A (Power Circuit), 10 A (Signalling Circuit) |
| Max. Operating Watts | 4 kW (at 480V AC 50/60 Hz AC-3), 4 kW (at 500 to 600V AC 50/60 Hz AC-3), 4 kW (at 660 to 690V AC 50/60 Hz AC-3), 2.2 kW (at 400V AC 50/60 Hz AC-4), 3 kW (at 220 to 230V AC 50/60 Hz AC-3), 5.5 kW 380 to (at 415V AC 50/60 Hz AC-3), 5.5 kW (at 440V AC 50/60 Hz AC-3), 4 kW (at 480V AC 50/60 Hz AC-3e), 4 kW (at 500 to 600V AC 50/60 Hz AC-3e), 4 kW (at 660 to 690V AC 50/60 Hz AC-3e), 3 kW (at 220 to 230V AC 50/60 Hz AC-3e), 5.5 kW (at 380 to 415V AC 50/60 Hz AC-3e), 5.5 kW (at 440V AC 50/60 Hz AC-3e) |
| Signalling Circuit Frequency | Less Than 400 Hz |
| Hold VA | 4.5 VA |
| Rated Insulation Volts | 600/690V |
| Rated Breaking Capacity | 110 A @ 440V, 80 A @ 500V, 70 A @ 660 to 690V |
| Operating Speed | 3600 cycles per hr |
| Watts Loss | 1.3W |
| Impulse Withstand Voltage | 8 kV |
| Operating Time | 10 to 20 ms (Coil De-Energisation and NO Opening), 10 to 20 ms (Coil Energisation and NO Closing) |
| Insulation Resistance Range | Greater Than 10 MOhms (Signalling Circuit) |
| Switching Current | 5 mA (Signalling Circuit) |
| NEMA Enclosure Rating | No Enclosure |
| Resistance Properties | Insulation Resistant |
| Maximum Voltage Rating | 690V AC |
| Mounting Style | DIN Rail, Plate |
| Horsepower @ Three Phase - 480V AC | 7 1/2 hp |
| Frequency | 50/60 Hz |
| Full Load Current - Resistive | 20 A |
| Full Load Current - Inductive | 12:00 AM |
| Horsepower @ Three Phase - 240V AC | 3 hp |
| Electrical Operating Durability | 1,300,000, 300,000 |
| Number of Normally Open Main Contacts | 3 |
| Contactor Style | IEC |
| Horsepower @ Single Phase - 240V AC | 2 hp |
| Horsepower @ Single Phase - 120V AC | 1/2 hp |
| Embedded Surge Suppressor | No |
| Mechanical Operating Durability | 10,000,000 |
| Includes Auxiliary Contacts | Yes |
| Horsepower @ Three Phase - 600V AC | 10 hp |
| Conventional Free Air Thermal Current | 20 A (at 50°C Power Circuit), 10 A (at 50°C Signalling Circuit) |
Description
The Square D LC1K1210G7 is an IEC miniature magnetic contactor from the TeSys series. This non-reversing, three-pole contactor uses a 120V AC coil and screw-clamp terminals to open and close electrical circuits, and includes one normally open auxiliary contact. It is rated for 20A and carries certifications including UL Listed, CSA, IEC 60947, and UKCA.
| Shipping | This item ships to USA |
Processing Time:
