- Amps: 10 A
- Voltage: 690V AC
- Maximum Voltage Rating: 690V AC
- Ambient Air Temperature For Operation: 23 to 140°F (-5 to 60°C)
- IRMS Rated Making Capacity: 140 A AC conforming to IEC 60947-5-1; 250 A DC conforming to IEC 60947-5-1
- Minimum Switching Voltage: 17 V
Specifications
| Part Number | LADN04 |
| Brand | Schneider Electric |
| Number of NO Aux. Contacts | 0 |
| Number of NC Aux. Contacts | 4 |
| Amps | 10 A |
| Mounting | Front |
| For Use With | Schenider LC1F Contactors |
| Depth | 42 mm |
| Height | 48 mm |
| Width | 44 mm |
| Item | Auxiliary Contact Block |
| Max. Contact Blocks (No.) | 1 |
| Number of Contacts | 4 |
| Voltage | 690V AC |
| Color | Dark Gray |
| Features | Mercury Free, Toxic Heavy Metal Free |
| Standards | EN/IEC 60947-5-1, UL 60947-5-1, CSA C22.2 No 60947-5-1, GB/T 14048.5, CB, CCC, EAC, UKCA |
| Current AC | 10 A |
| IP Rating | IP20 |
| Number of Normally Closed Contacts | 4 |
| Compatible with Series | TeSys, TeSys Deca, TeSys F |
| Number of Normally Open Contacts | 0 |
| Maximum Voltage Rating | 690V AC |
| Terminal Connection Type | Screw Clamp Terminals |
| Ambient Air Temperature For Operation | 23 to 140°F (-5 to 60°C) |
| Product Name | TeSys Deca |
| Mechanical Durability | 30 Mcycles |
| Non-Overlap Time | 1.5 ms on de-energisation no overlap between NC and NO contact; 1.5 ms on energisation no overlap between NC and NO contact |
| Operating Altitude | 9842.52 ft (3000 m) |
| IRMS Rated Making Capacity | 140 A AC conforming to IEC 60947-5-1; 250 A DC conforming to IEC 60947-5-1 |
| Protective Treatment | TH IEC 60068 |
| Range Compatibility | TeSys D LC1D; TeSys D CAD; TeSys F LC1F; TeSys F CR1F; TeSys Deca CAD; TeSys Deca LC1D |
| Protection Type | GG fuse 10 A |
| Rated Operational Current | 6 A at 120 V AC-15; 1.04 A at 690 V AC-15; 0.55 A at 125 V DC-13; 0.1 A at 600 V DC-13 |
| Pole Contact Composition | 4 NC |
| Minimum Switching Current | 5 mA |
| Insulation Resistance | Greater than 10 MOhm |
| Permissible Short-Time Rating | 100 A 1 s; 120 A 500 ms; 140 A 100 ms |
| Minimum Switching Voltage | 17 V |
| Conventional Free Air Thermal Current | 10 A (at 140°F (60°C)) |
| Rated Operational Voltage | 690 V AC 25 to 400 Hz |
| Contacts Operation | Instantaneous |
| Tightening Torque | 15.05 lbf.in (1.7 N.m) flat 6 mm; 15.05 lbf.in (1.7 N.m) Philips No 2; 15.05 lbf.in (1.7 N.m) pozidriv No 2 |
| Product Certifications | CB; UL; CSA; CCC; EAC; UKCA |
| Ambient Air Temperature For Storage | -76 to 176°F (-60 to 80°C) |
| Rated Insulation Voltage | 690 V IEC 60947-5-1; 600 V UL; 600 V CSA |
| IP Degree Of Protection | IP20 conforming to IEC 60529 |
| Connections - Terminals | screw clamp terminals 1 0.00 to 0.01 in² (1 to 4 mm²)flexible with cable end; screw clamp terminals 1 0.00 to 0.01 in² (1 to 4 mm²)flexible without cable end; screw clamp terminals 2 0.00 to 0.00 in² (1 to 2.5 mm²)flexible with cable end; screw clamp terminals 2 0.00 to 0.01 in² (1 to 4 mm²)flexible without cable end; screw clamp terminals 1 0.00 to 0.01 in² (1 to 4 mm²)rigid without cable end; screw clamp terminals 2 0.00 to 0.01 in² (1 to 4 mm²)rigid without cable end |
| Environmental Characteristic | Normal environment |
Description
The LADN04 from Schneider Electric is an IEC auxiliary contact block, specifically a TeSys contacts block. It provides four normally closed (NC) auxiliary contacts with a rating of 10 A at 690V AC. This auxiliary contact block is designed for use with Schneider LC1F contactors.
