- Housing Material: Plastic
- Voltage: 120v
- Max. Amps: 0.54 A
- Max. Wattage: 65/54
- Overall Diameter: 7 7/8 in
- Duct Diameter: 6 in
Specifications
| Part Number | KIT-TD150 |
| Brand | Soler & Palau |
| Housing Material | Plastic |
| Fits Duct Dia. | 6 in |
| Voltage | 120v |
| Max. Amps | 0.54 A |
| Max. Wattage | 65/54 |
| Housing Dia. | 7 7/8 in |
| Length | 8 3/8 in |
| Inlet and Outlet Dia. | 5 7/8 in |
| Flange Width | 1 1/8 in |
| Overall Diameter | 7 7/8 in |
| Duct Diameter | 6 in |
| Overall Width | 5 in |
| Overall Height | 5 in |
| Item | In-Line Duct Fan |
| Number of Speeds | 1 |
| Motor RPM | 2300/1700 |
| CFM @ 0.000-In. SP | 293/218 |
| CFM @ 0.500-In. SP | 206/105 cfm |
| Max. Inlet Temp. | 104 Degrees F |
| Standards | cULus |
| Mounting Position | Horizontal or Vertical |
| Speed Control | Mfr. No. 48C172 |
| CFM @ 0.125-In. SP | 273/193 cfm |
| CFM @ 0.375-In. SP | 227/128 cfm |
| Motor HP | 1/10 hp |
| CFM @ 0.250-In. SP | 227/128 cfm |
| Hz | 60 |
| Motor Enclosure | Totally Enclosed |
| CFM @ 1.000-In. SP | 35 cfm |
| Phase | 1 |
| CFM @ 0.750-In. SP | 131/24 cfm |
| Includes | (1) Exterior Termination Louver, (1) Intake Grill, Mounting Bracket |
| Bearing Type | Ball Bearing |
| For Fan Type | In-Line Duct Fan |
| Maximum Inlet Air Temperature | 104 Degrees F |
| Motor IP Rating | IP44 |
| Nameplate Voltage | 120V AC |
| Motor Output Power | 65 W |
| High-Efficiency Motor | No |
| Motor Speed | 2,300 RPM |
| Airflow @ 0.000 in SP | 293 cfm |
| Speed Controllable | Yes |
| Application | General Purpose |
| Mounting Orientation | Horizontal or Vertical |
Description
The Soler & Palau KIT-TD150 is a 6-inch in-line mixed flow duct fan kit. This fan moves air through ductwork, operating at 120V with a maximum of 0.54 amps and 65/54 watts, with motor speeds of 2300/1700 RPM. It is constructed with a plastic housing, has a maximum inlet temperature of 104 degrees Fahrenheit, and is cULus listed.
