- Phase: 3
- HP @ 3 Phase - 575V: 20 hp
- Phase Loss Sensitivity: Yes
- HP @ 3 Phase - 460-575V: 15/20
- HP @ 1 Phase - 230V: 3 hp
- Horsepower @ Single Phase - 120V AC: 2 hp
Specifications
| Part Number | GV2P22 |
| Brand | Square D |
| Number of Poles | 3 |
| Operator | Rotary Knob |
| Phase | 3 |
| Current AC | 25 A |
| Series | TeSys Deca |
| Overall Depth | 3.82 in |
| Overall Width | 1.77 in |
| Overall Height | 3.5 in |
| Item | Manual Motor Starter |
| Standards | ATEX Compliant, BV, CCC, CSA, DNV-GL, EAC, EN/IEC 60947-2, EN/IEC 60947-4, LROS, RINA, UKCA, UL Listed |
| Pilot Light | Yes |
| HP @ 3 Phase - 575V | 20 hp |
| Description/Special Features | Reliable Overload Protection |
| Phase Loss Sensitivity | Yes |
| HP @ 3 Phase - 460-575V | 15/20 |
| HP @ 1 Phase - 230V | 3 hp |
| Horsepower @ Single Phase - 120V AC | 2 hp |
| Minimum Overload Relay Current Setting | 20 A |
| Horsepower @ Three Phase - 208V AC | 5 hp |
| Overload Protection Type | Thermal |
| IP Rating | IP20 |
| Horsepower @ Three Phase - 600V AC | 20 hp |
| Horsepower @ Three Phase - 480V AC | 15 hp |
| Frequency | 50/60 Hz |
| Starter Style | IEC |
| Minimum Operating Temperature | -4 Degrees F |
| Maximum Operating Temperature | 140 Degrees F |
| NEMA Enclosure Rating | No Enclosure |
| Mechanical Operating Durability | 100,000 |
| Horsepower @ Single Phase - 240V AC | 3 hp |
| Terminal Connection Type | Screw Clamp Terminals |
| Resistance Properties | Fire Resistant |
| Includes Pilot Light | No |
| Horsepower @ Three Phase - 240V AC | 7 1/2 hp |
| Electrical Operating Durability | 100,000 |
| Maximum Voltage Rating | 600V AC |
| Product Name | TeSys GV2 || TeSys Deca |
| Color | dark grey |
| [Uimp] Rated Impulse Withstand Voltage | 6 kV IEC 60947-2 |
| Utilisation Category | category A IEC 60947-2 || AC-3 IEC 60947-4-1 |
| Tightening Torque | 1.7 N.m screw clamp terminal |
| Operating Altitude | 6561.68 ft (2000 m) |
| Phase Failure Sensitivity | yes IEC 60947-4-1 |
| Power Dissipation Per Pole | 2.5 W |
| Fixing Mode | 35 mm symmetrical DIN rail clipped || panel screwed with 2 x M4 screws) |
| Rated Duty | continuous IEC 60947-4-1 |
| Range | TeSys Deca |
| Trip Unit Technology | thermal-magnetic |
| Network Type | AC |
| Mechanical Robustness | shocks 30 Gn for 11 ms || vibrations 5 Gn, 5...150 Hz |
| Magnetic Tripping Current | 327-327 A |
| Ambient Air Temperature For Storage | -40-80°C |
| Climatic Withstand | IACS E10 |
| Fire Resistance | 960°C IEC 60695-2-11 |
| Ik Degree Of Protection | IK04 |
| Suitability For Isolation | yes IEC 60947-1§ 7-1-6 |
| Device Application | motor protection |
| Thermal Protection Adjustment Range | 20-25 A IEC 60947-4-1 |
| Motor Power Kw | 11-11 kW 400/415 V AC 50/60 Hz || 15-15 kW 500 V AC 50/60 Hz |
| Device Short Name | GV2P |
| Rated Service Short-Circuit Breaking Capacity | 100 % 230/240 V AC 50/60 Hz IEC 60947-2 || 50 % 400/415 V AC 50/60 Hz IEC 60947-2 || 75 % 440 V AC 50/60 Hz IEC 60947-2 || 75 % 500 V AC 50/60 Hz IEC 60947-2 || 100 % 690 V AC 50/60 Hz IEC 60947-2 |
Description
The Square D GV2P22 is a TeSys Deca manual motor starter. This device provides overload protection for three-phase motors and is sensitive to phase loss. It is rated for 25 A, 690 VAC, and is UL Listed and ATEX Compliant, with horsepower ratings of 20 hp at 575V and 15/20 hp at 460-575V.
