- Connection Size: 1/2 in. NPT
- Roller Diameter: 0.75 in
- Mounting Hole Diameter: 0.21 in
- Body Material: Metal
- NEMA Rating: 1, 12, 13, 4
- Roller Material: Steel
Specifications
| Part Number | GLCA01A2B |
| Brand | Honeywell |
| Basic Actuator Style - Limit Switch | Rotary |
| Actuator Style - Limit Switch | Roller Lever, Rotary |
| Contact Form- Switches | 1NC/1NO |
| Actuator Location - Limit Switch | Side |
| AC Contact Rating - Limit Switch | 10A at 300V |
| Body Height - Limit Switch | 2.17 in |
| Body Width - Limit Switch | 1.2 in |
| Width | 1.20" |
| Body Depth - Limit Switch | 1.18 in |
| Depth | 1.18" |
| Roller Dia. | 0.75 in |
| Roller Width | 0.25 in |
| Height | 2.16" |
| Actuator Length - Limit Switch | 1.34 in to 3.11 in |
| Connection Size | 1/2 in. NPT |
| Roller Diameter | 0.75 in |
| Mounting Hole Diameter | 0.21 in |
| Body Depth | 1.18 in |
| Body Width | 1.2 in |
| Body Height | 2.17 in |
| Item | Limit Switch |
| DC Contact Rating - Limit Switch | 10A at 250V |
| Body Style - Limit Switch | Miniature |
| Mounting - Limit Switch | Surface |
| Boot Sealed Actuator - Limit Switch | No |
| Body Material | Metal |
| IP Rating | IP66 |
| NEMA Rating | 1, 12, 13, 4 |
| Actuator Style | Roller Lever Plunger |
| Basic Actuator Style (Limit Switch) | Rotary |
| Series | GLC |
| Movement | CCW, CW |
| Mounting Hole Pattern - Limit Switch | 4 Hole Rectangular |
| Actuator Location | Side |
| AC Contact Rating | 10 A @ 300 V |
| Body Style (Limit Switch) | Miniature |
| Mounting Hole Spacing - Limit Switch | 2.36 in x 1.18 in |
| Contact Form | 1NO/1NC |
| Limit Switch Style | General Purpose Limit Switch |
| Actuator Location (Limit Switch) | Side |
| Roller Material | Steel |
| Mounting Hole - Limit Switch | (4) 0.21 in dia |
| Arm Material | Steel |
| Stem Thread - Limit Switch | No Stem |
| Number of Poles | 1 |
| Amps | 10 |
| Wiring Entry | 1/2 in NPT |
| Operating Temp. Range | -40 Degrees to 185 Degrees F |
| Travel | Differential Travel 11.5 Degrees , Maximum Pretravel 26 Degrees , Minimum Over Travel 49 Degrees , Operating Position 26 Degrees |
| Voltage Rating | 300VAC/250VDC |
| Contact Form - Limit Switch | 1NC/1NO |
| DC Contact Rating | 10 A @ 250 V |
| Standards | CCC, CE, CSA, UL Listed |
| Electrical Connection | Screw Terminals |
| Boot Sealed Actuator (Limit Switch) | No |
| Operating Force | 1.1 in-lb |
| Actuator Style (Limit Switch) | Rotary, Roller Lever |
| Differential Travel | 11.5 Degrees |
| Connection Type | Threaded Entry |
| Differential-Travel - Travel To Reset | 11.5 deg DT |
| Head/Operator | Side Rotary Roller Lever |
| Pre-Travel - Travel To Operate | 26 deg PT |
| Head Action | Spring Return, Standard |
| Operating Temperature - max | 185 deg F (85 deg C) |
| Electrical Rating - VAC/DC | 10A 600Vac (Vdc Rated) |
| Poles/Contacts | SPDT 1NO 1NC |
| Current Rating - nominal | 10A |
| Operator Configuration | Adjustable |
| Over-Travel/Total-Travel | 49 deg OT |
| Operating Temperature - min | -13 deg F (-25 deg C) |
| Body Construction | Die Cast Zinc |
| Rating - NEMA | NEMA 4 |
| Travel Direction | CW or CCW |
| Number of Mounting Holes | 4 |
| Body Configuration | Non Plug-In |
| Mounting Style | Surface |
| NEMA Enclosure Rating | 1, 12, 13, 4 |
| Pretravel | 26 Degrees |
| Mounting Hole Vertical Center to Center Distance | 60 mm |
| Operating Torque - Maximum | 1.1 in-lb |
| Boot Sealed Actuator | No Boot Included |
| Operating Temperature - Maximum | 185 Degrees F |
| Directional Movement | CCW/CW |
| Overtravel | 49 Degrees |
| Operating Temperature - Minimum | -40 Degrees F |
| Mounting Hole Horizontal Center to Center Distance | 30 mm |
Description
The Honeywell GLCA01A2B is a GLC Series Limit Switch with a side-mounted rotary roller lever actuator. This limit switch uses a roller lever to detect the presence or position of an object, opening or closing an electrical circuit. It is a single-pole, double-throw (SPDT) device with AC and DC contact ratings of 10A at 300V and 10A at 250V, respectively, and features a die-cast zinc housing with an IP67 rating.
