- Voltage: 120V AC
- For Shaft Diameter: 1 in
- Ambient Temp. Range: -25 Degrees to 130 Degrees F
- Minimum Operating Temperature: -25 Degrees F
- Input Voltage: 120V AC
- Housing Material: Aluminum
Specifications
| Part Number | GCA221.1U |
| Brand | Siemens |
| Mounting Type | Direct Mount |
| Signal Type | On/Off |
| Torque | 160 in-lb |
| Voltage | 120V AC |
| Height | 11 13/16 in |
| Width | 3 15/16 in |
| Depth | 2 11/16 in |
| For Shaft Height | 3/4 in |
| Overall Height | 11 3/4 in |
| For Shaft Diameter | 1 in |
| Overall Depth | 2 7/8 in |
| Overall Width | 4 3/4 in |
| For Shaft Width | 3/4 in |
| Type | Spring-Return |
| Motor Direction | CW or CCW |
| Electrical Connections | 3 ft 18 AWG Lead |
| Stroke Deg. | 90 |
| For Use With | Dampers that Require Up to 160 in-lb Torque |
| Power Consumption | 8 VA |
| Shaft Type | Self-Centering Shaft Coupling |
| Timing | 90 sec |
| Replaces Honeywell Motors | Mfr. No. MS4120 |
| Ambient Temp. Range | -25 Degrees to 130 Degrees F |
| Includes | Mounting Bracket |
| Item | Actuator |
| Minimum Operating Temperature | -25 Degrees F |
| Number of Auxiliary Switches | 0 |
| IP Rating | IP54 |
| Output Signal | 0 to 10V DC |
| Electrical Connection Type | Hardwired |
| Valve Application | Damper |
| Input Voltage | 120V AC |
| Product Type | Actuator |
| Stroke Degree | 90 Degrees |
| Weight | 4.85 lb |
| Time to Open | 90 sec |
| Rated Torque | 160 in-lb |
| For Shaft Shape | Round, Square |
| Time to Close | 15 sec |
| For Use With Building Automation Systems | Building Automation System Compatible |
| Housing Material | Aluminum |
| Maximum Operating Temperature | 130 Degrees F |
| Standards | CE Certified, cUL (C22.2 No. 24-93) Listed, UL 60730 |
| NEMA Rating | 2 |
| Shaft Rotation | CW/CCW |
| Application | Dampers |
Description
The Siemens GCA221.1U is a 120V AC, on/off, spring-return electric actuator. It provides up to 160 in-lb of torque to open and close dampers. This actuator is used with dampers that require up to 160 in-lb of torque and features a self-centering shaft coupling.
