- Amp Range: 31 to 60A
- Voltage Rating: 300V AC/DC
- Wire Size: 14 to 2 AWG
- For Fuse Size: 2-1/4 in L x 7/16 in dia
- For Fuse Diameter: 13/32 in
- Wire Size - Maximum: 2 AWG
Specifications
| Part Number | G30060-3CR |
| Brand | Bradford White |
| UL Class | G |
| Series | G |
| Number of Poles | 3 |
| Amp Range | 31 to 60A |
| Voltage Rating | 300V AC/DC |
| Wire Size | 14 to 2 AWG |
| Length | 3.56 in |
| Width | 2-3/4 in |
| Height | 1.41 in |
| For Fuse Size | 2-1/4 in L x 7/16 in dia |
| Overall Height | 1.41 in |
| For Fuse Length | 2 1/4 in |
| Overall Length | 3.56 in |
| For Fuse Diameter | 13/32 in |
| Wire Size - Maximum | 2 AWG |
| Overall Width | 2.75 in |
| Item | Open Fuse Block |
| Connector Type | Box Lug |
| Mounting Style | Bolt-Down |
| Visual Indication | Non-Indicating |
| Fuse Block Style | Rejection |
| Fuse Block Design | Open |
| Body Material | Polyester |
| For Fuse Series | SC |
| Fuse Type | Industrial |
| Standards | CSA, RoHS, UL |
| Fuse Holder Code | AK |
| Fits Fuse Type | Class G |
| Wire Range | 8 AWG to 2 AWG, 14 AWG to 2 AWG |
| Weight | .442 lb |
| Fits Fuse Block Style | Non-Rejection |
| Fuse Block or Holder AC Voltage Rating | 480VAC |
| Fuse Block or Holder DC Voltage Rating | 300VDC |
| AC Voltage Rating | 480 V AC |
| DC Voltage Rating | 300 V DC |
| Current - Maximum | 60 A |
| Current - Minimum | 31 A |
Description
The Bradford White G30060-3CR is an open fuse block. This type of part provides a mounting point and electrical connections for fuses, allowing for safe disconnection and overcurrent protection in a circuit. It is rated for 31 to 60A at 300V AC/DC, has a polyester body, and uses box lug connectors for SC series industrial fuses.
