- Voltage: 120V AC
- Phase: 1
- Duct Diameter: 4 in
- Amps: 0.1/0.14/0.24
- Housing Material: Zinc; Aluminum; Magnesium
- Grille Material: Polypropylene
Specifications
| Part Number | FV-0511VH1 |
| Brand | Panasonic |
| Voltage | 120V AC |
| CFM @ 0.100-In. SP | 50/80/110CFM |
| Includes | Mounting Brackets |
| Phase | 1 |
| Watts | 4.7/7.7/12 |
| Duct Dia. | 4 or 6 in |
| Grille Length | 13 1/2 in |
| Grille Width | 18 1/2 in |
| Housing Length | 16 in |
| Housing Width | 10 1/4 in |
| Housing Height | 7 1/2 in |
| Profile Height Family | Medium |
| For Cut-Out Width | 10 1/4 in |
| Profile Width Family | Single-Wide |
| Overall Depth | 10 1/4 in |
| Overall Width | 16 in |
| Overall Height | 7 1/2 in |
| For Cut-Out Length | 16 in |
| Duct Diameter | 4 in |
| Amps | 0.1/0.14/0.24 |
| Housing Material | Zinc; Aluminum; Magnesium |
| Number of Speeds | 3 |
| Sones @ 0.100-In. SP @ 5 Ft. | Less Than0.3/ Less Than0.3/0.7 |
| Lighted | Without Light |
| Heater | With Heater |
| Motion Sensing | No |
| Profile | Medium |
| Grille Material | Polypropylene |
| Discharge | Vertical |
| Item | Fan/Heater Combination |
| Standards | cUL Listed, HVI Certified |
| Motor Type | Electronically Commutated |
| Night-Light | No |
| Nominal RPM | 638/736/861RPM |
| Humidity Sensing | No |
| Heat Watts | 1600 |
| Hz | 60 Hz |
| Motor Enclosure | Enclosed |
| Requires | Minimum 20 Amp Dedicated Circuit |
| Noise Level @ 0.100 in SP @ 5 ft | 0.7 sones |
| Maximum Noise Level | 1.5 sones |
| Discharge Direction | Vertical |
| Motor Speed | 638 RPM, 736 RPM, 861 RPM, 930 RPM, 1,008 RPM, 1,090 RPM, 1,112 RPM, 1,173 RPM, 1,249 RPM |
| Includes Grill | Yes |
| Blower Wheel Curve | Forward |
| Heater Type | Heating Coil |
| Noise Level @ 0.250 in SP @ 5 ft | 8 sones |
| Frequency | 60 Hz |
| Heater Wattage | 1,600 W |
| Sensor Type | None |
| Exhaust Airflow @ 0.100 in SP | 50 cfm, 80 cfm, 110 cfm |
| Nameplate Voltage | 120V AC |
| Vent Design | Ducted |
| Full Load Current | 0.1 A, 0.16 A, 0.18 A, 0.24 A, 0.25 A, 0.26 A, 0.35 A, 0.37 A, 0.49 A, 0.5 A |
| Duct Shape | Round |
| Exhaust Airflow @ 0.250 in SP | 51 cfm, 82 cfm, 112 cfm |
Description
The Panasonic FV-0511VH1 is a Fan/Heater Combination. This unit functions as both a ventilation fan and a heater, operating at 120V AC with three CFM settings of 50, 80, and 110. It is cUL Listed and HVI Certified, and includes mounting brackets.
