- For Container Size: 55 gal
- Discharge Size FPT: 3/4
- Pump Mount Size: 2"
- Inlet Size: 1" NPT
- Spout Connection Size: 3/4 in
- Wetted Materials: Aluminum, Buna-N, Delrin
Specifications
| Part Number | FR150 |
| Brand | Fantech |
| Action Type | Lever |
| For Media Type | Antifreeze, Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, E85, Ethylene Glycol, Gasoline, Glycerin, Hydraulic Oils, Kerosene, Motor Oils, Stoddard Solvent |
| For Container Size | 55 gal |
| Max. Flow Rate | 20 gal per 100 strokes |
| Max. Viscosity | 50 SUS |
| Overall Width | 10 |
| Discharge Size FPT | 3/4 |
| Pump Mount Size | 2" |
| Overall Length | 6 |
| Manufacturers Warranty Length | 2 yr. |
| Inlet Size | 1" NPT |
| Overall Height | 19-3/4" |
| Length | 6" |
| Spout Connection Size | 3/4 in |
| Height Above Container | 19 1/2 in |
| Spout Length | 3 in |
| Bung Connection Dia. | 2 in |
| Item | Hand Operated Drum Pump |
| Diesel Exhaust Fluid Compatible | No |
| Wetted Materials | Aluminum, Buna-N, Delrin |
| Includes Suction Tube | No |
| For Use With | Diesel/Fuel Oil |
| Discharge Tube Outlet ID | 3/4 in |
| Discharge Tube Outlet OD | 7/8 in |
| Standards | UL Listed |
| Self-Priming | Yes |
| Pressure Range | 38 psi |
| Agency Compliance | cUL/UL Listed |
| Seal Material | Buna-N |
| Seal Type | Mechanical |
| Bypass Valve | No |
| Ounces per Stroke | 25 oz. |
| Includes | Pump Only |
| Features | Anti-Siphon Valve, Can Be Used to Pump In Reverse Direction, Piston Hand Pump |
| Piston Material | Aluminum |
| Pump Design | Rotary Vane |
| Metered | No |
| Max. Flow GPM | 10 |
| Adapter Material | Cast Iron |
| Food Grade | No |
| For Container Type | Drum |
| Housing Material - Pumps | Aluminum |
| Spout Material | Aluminum |
| Pump Connection OD | 2 1/8 in |
| Not Recommended Chemicals | See full list of Not Recommended Chemicals Acetic Acid (Glacial),Acetic Acid 20%,Acetic Acid 80%,Acetone,Ammonia (Liquids),Ammonium Hydroxide,Anhydrous Ammonia,Calcium Chloride,Chromic Acid 10%,Chromic Acid 30%,Chromic Acid 5%,Chromic Acid 50%,Citric Acid 50%,Cyclohexane,DEF,Deionized Water,Ethyl (Ethanol),Ethyl Acetate,Fertilizers,Formic Acid,Fresh Water,Fungicides,Heptane,Herbicides,Hexane,Hydrochloric/Muriatic Acid (100%),Hydrochloric/Muriatic Acid (20%),Hydrochloric/Muriatic Acid (37%),Hydrofluoric Acid (20%),Hydrofluoric Acid (75%),Hydrofluoric Acid 100%,Isopropyl (Isopropanol),Lacquer Thinners,Lithium Grease,Methyl (Methanol),Methyl Chloride,Methyl Ethyl Ketone (MEK),Naphtha,Nitric Acid (10% Solution),Nitric Acid (20% Solution),Nitric Acid (50% Solution),Nitric Acid (Concentrated Solution),Paint,Paint Thinner,Pesticides,Phosphoric Acid (40% Solution),Potassium Hydroxide (50%),Salt Water,Sodium Bicarbonate (10%),Sodium Bisulfate,Sodium Bisulfite,Sodium Hydroxide/Caustic Soda (20%),Sodium Hydroxide/Caustic Soda (50%),Sodium Hydroxide/Caustic Soda (80%),Sodium Hypochlorite/Bleach (to 20%),Sulfuric Acid (10% - 75%),Sulfuric Acid (75% - 100%),Sulfuric Acid (to 10%),Toluene,Trichlorethylene (50%),Turpentine,Windshield Washer Fluid,Xylene |
| Series | 5200 SERIES, PISTON HAND PUMPS |
| Power Source | Hand Operated |
| Includes Bung Adapter | Yes |
| Pump Connection ID | 2 in |
| Includes Discharge Hose | No |
| Runs Dry | Yes |
| Max. Head Pressure | 50 psi |
| Max. Head - Pumps | 6 ft |
| Max. Fluid Temp. | 120 Degrees F |
| Includes Spout | Yes |
| Max. Oil Flow | 25 oz per stroke |
| Compatible Chemicals | Antifreeze, Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, E85, Ethylene Glycol, Gasoline, Glycerin, Hydraulic Oils, Kerosene, Motor Oils, Stoddard Solvent |
| Includes Nozzle | No |
| Min. Operating Temp. | 0 Degrees F |
| Discharge Connection Type | FNPT |
| Max. Outlet Pressure | 50 psi |
| Gear Lube | NT |
| Adapter Connection Type | MNPT |
| Mount Type | Bung |
Description
The Fantech FR150 is a hand-operated drum pump. This type of pump manually transfers fluids from a drum or container by using a lever action. It is compatible with a range of media including antifreeze, diesel fuel, gasoline, and motor oils, with a maximum flow rate of 20 gallons per 100 strokes.
