- Housing Material: Cast Iron
- Inlet Size: 1 in NPT
- Seal Material: Carbon
- Pump Mount Size: 2 in
- Outlet Size: 3/4 in NPT
- For Container Size: 55 gal
Specifications
| Part Number | FR110 |
| Brand | Fantech |
| Application | Designed for Gasoline, Diesel, Biodiesel up to B20, E-15 and Kerosene |
| Housing Material | Cast Iron |
| GPM | 10 gpm |
| Inlet Size | 1 in NPT |
| Seal Material | Carbon |
| Manufacturers Warranty Length | 2 yr |
| Overall Length | 6 1/4 in |
| Pump Mount Size | 2 in |
| Outlet Size | 3/4 in NPT |
| Overall Width | 9 1/2 in |
| Overall Height | 15 1/2 in |
| For Container Size | 55 gal |
| Bung Connection Dia. | 2 in |
| Pump Design | Rotary |
| Self-Priming | Yes |
| Seal Type | Mechanical |
| Max. Viscosity | 50 SUS |
| Item | Fuel Transfer Pump |
| Pressure Range | 38 psi |
| Standards | UL Listed |
| For Use With | Diesel/Fuel Oil |
| Bypass Valve | Yes |
| Metered | No |
| Compatible Fluids | Biodiesel up to B20, Diesel, E15, Gasoline, Kerosene |
| Transfer Pump Application | Agriculture, Construction, Farming |
| Features | Iron Rotor with Carbon Rotary Vanes, Pressure Relief Valve, Self Priming |
| Duty Cycle | Continuous |
| Agency Compliance | UL Listed |
| Wetted Materials | 301 Stainless Steel, Buna-N, Cast Iron, Zinc Plated Steel |
| Action Type | Rotary |
| Housing Material - Pumps | Aluminum |
| Pump Connection OD | 2 1/8 in |
| Includes Spout | No |
| Includes Bung Adapter | Yes |
| Compatible Chemicals | Biodiesel, Diesel Fuel, E15, Gasoline, Kerosene |
| Max. Flow Rate | 10 gal per 100 revolutions |
| Includes Discharge Hose | No |
| Adapter Connection Type | MNPT |
| Max. Head Pressure | 50 psi |
| Max. Fluid Temp. | 120 Degrees F |
| Max. Outlet Pressure | 38 psi |
| Includes Suction Tube | No |
| For Media Type | Biodiesel, Diesel Fuel, E15, Gasoline, Kerosene |
| Includes Nozzle | No |
| Mount Type | Bung |
| For Container Type | Drum |
Description
The Fantech FR110 is a fuel transfer pump with a 10 gpm maximum flow rate and a 38 psi pressure range. This type of pump moves fuel from one location to another. It is designed for use with gasoline, diesel, biodiesel up to B20, E-15, and kerosene. The pump features a cast iron housing, a carbon mechanical seal, and is UL Listed.
