- NEMA Rating: 1, 12, 13, 2, 4, 4X, 6P
- Amps: 10
- Voltage Rating: 600V AC
- Operating Temp.: 10 Degrees to 200 Degrees F
- Operating temperature - min: 10°F
- Operating temperature - max: 200°F
Specifications
| Part Number | E50DR1 |
| Brand | Eaton |
| Actuator Style | Rotary Lever |
| Actuator Location | Side |
| Actuator Length | 0.63 in |
| For Use With | Mfr. No. E50SA |
| NEMA Rating | 1, 12, 13, 2, 4, 4X, 6P |
| Product Length/Depth | 1.05 in |
| Product Width | 1.54 in |
| Product Height | 2.46 in |
| Overall Depth | 1.05 in |
| Arm Length - Maximum | 0.63 in |
| Manufacturer Warranty Length | 1 yr |
| Overall Height | 2.46 in |
| Overall Width | 1.54 in |
| Item | Limit Switch Head |
| Movement | CW and CCW |
| Travel | Operating Travel 5 Degrees , Reset Travel 2 Degrees , Total Travel 90 Degrees |
| Operating Force | 2.2 N |
| Amps | 10 |
| Description/Special Features | Spring Return Rotary |
| Voltage Rating | 600V AC |
| Operating Temp. | 10 Degrees to 200 Degrees F |
| Standards | CSA, RoHS, UL Listed |
| IP Rating | IP67 |
| Actuator | Side rotary, standard spring return |
| Operating temperature - min | 10°F |
| Operating temperature - max | 200°F |
| Certifications | CSA Certified |
| Environmental rating | NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67 |
| Series | E50 |
| Enclosure material | Die cast zinc |
| Product Name | Eaton E50 NEMA heavy duty plug-in limit switch |
| Operating Temperature - Minimum | 10 Degrees F |
| Reset Travel | 2 Degrees |
| Operating Temperature - Maximum | 200 Degrees F |
| Pretravel | 5 Degrees |
| Compatible with Manufacturer Model Number | E50SA |
| Overtravel | 5 Degrees |
| Features | Spring Return |
| Total Travel | 90 Degrees |
| Operating Torque | 3 in-lb |
| Compatible with Brand | Eaton |
| Differential Travel | 90 Degrees |
| NEMA Enclosure Rating | 1, 13, 3, 3S, 4, 4X, 6, 6P |
| Directional Movement | CCW/CW |
| Compatible with Series | E50 |
| Action | Momentary |
| Includes Actuator | No Actuator Included |
| Compatible Manufacturer Part Number | E50SA |
| Compatible Manufacturer Model Number | E50SA |
| Compatible with Manufacturer Model No. | E50SA |
| Compatible with Mfr. Model No. | E50SA |
| For Use with Mfr Model Number | E50SA |
| For Use With Mfr. Model Number | E50SA |
| Compatible Pump Manufacturer Part Number | E50SA |
| Compatible Mfr. Model Number | E50SA |
Description
The Eaton E50DR1 is a limit switch head with a side-mounted rotary lever actuator and spring return. This type of switch head detects the presence or position of an object by opening or closing an electrical circuit when the lever is actuated. It is designed for use with the Eaton E50SA and carries NEMA ratings of 1, 2, 4, 4X, 6P, 12, and 13, with a 10 amp rating and an operating force of 2.2 N.
