- Pressure Range (In. WC): 0.25 to 0 to 0.25
- Process Connection Size: 1/4 in
- Diameter - Transmitter: 4.75 in
- Process Connection Size - Transmitter: 1/8 in
- Diameter: 4.75 in
- Overall Diameter: 4.75 in
Specifications
| Part Number | DM-002 |
| Brand | Dwyer Instruments |
| Pressure Range (In. WC) | 0.25 to 0 to 0.25 |
| Accuracy | +/-1% of Full Scale |
| Output | 4 to 20mA DC |
| Power Required | 10 to 35V DC |
| Process Connection Type | Hose Barb |
| Process Connection Size | 1/4 in |
| Diameter - Transmitter | 4.75 in |
| Overall Depth - Transmitter | 1.69 in |
| Process Connection Size - Transmitter | 1/8 in |
| Overall Length | 1.69 in |
| Housing Length | 4 3/4 in |
| Diameter | 4.75 in |
| Housing Height | 4 3/4 in |
| Overall Diameter | 4.75 in |
| Item | Indicating Differential Transmitter |
| Connection Location | Side |
| Operating Temp. - Transmitter | 20 Degrees to 120 Degrees F |
| Series | DM-002 |
| Standards | CE, RoHS |
| Pressure Range Minor Div. | 0.005 in wc |
| Wiring Entry - Transmitter | None |
| Connection | 1/8" Barbed Fitting |
| Loop Resistance | 0 to 1250 ohms |
| Transmitter Type | Compound Transmitter |
| Shape - Transmitter | Round |
| Output - Transmitter | 4 to 20mA DC |
| Display - Transmitter | 3-1/2 Digit LCD |
| Accuracy - Transmitter | +/-1.00% Full Scale |
| Connection Location - Transmitter | Side |
| Power Required - Transmitters | 10 to 35V DC |
| Includes | Instructions |
| Range Units - Transmitter | in wc/in wc |
| Process Connection Type - Transmitter | Hose Barb |
| Output Accuracy | +/-1% Full Scale |
| Range Values - Transmitter | -0.25 to 0 to 0.25 |
| Electrical Connections - Transmitter | Screw Terminals |
| Thermal Error | +/-0.055% |
| Display Units | bar, in wc, kPa, mbar, mm wc, psi |
| Features | Zero and Span Controls |
| Display Type | Digital |
| Number of Digits | 3 1/2 |
| Display Screen Type | LCD |
| Electrical Connections | Screw Terminals |
| Shape | Round |
| Primary Scale Units | in wc |
| Maximum Loop Resistance | 1250 Ohm |
| Primary Scale Range | 0 to +/-.250 in wc |
| Minimum Operating Temperature | 20 Degrees F |
| Number of Wires | 2 |
| Maximum Operating Temperature | 120 Degrees F |
| NIST Traceable Certificate | No |
| For Use With Media Type | Air, Compatible Gases, Non-Combustible Gases |
| Minimum Pressure | 0 in wc |
| Housing Material | Glass |
| Weight | 4.8 oz |
| Overpressure | 10 psi |
| Maximum Pressure | 0.25 in wc |
| Pressure Units | in wc |
| Digital Display Screen Type | LCD |
| Pressure Measurement - Maximum | 0.3 in wc |
| Process Media Temperature - Minimum | 20 Degrees F |
| Pressure Measurement - Minimum | 0 in wc |
| Includes NIST-Traceable Calibration Certificate | No NIST-Traceable Calibration Certificate Included |
| Input Voltage | 10 to 35V DC |
| Loop Resistance - Maximum | 1250 Ohm |
| Output Power | 4 to 20mA DC |
| Process Connection Location | Side |
| Process Media Temperature - Maximum | 120 Degrees F |
| Electrical Connection | Screw Terminals |
Description
The Dwyer Instruments DM-002 is an indicating differential transmitter. This sensor measures the difference in pressure between two points and converts it into a proportional output signal. It has a pressure range of 0.25 to 0 to 0.25 inches of water column and features 1/4 inch hose barb process connections.
