- HP: 1/4 hp
- Nameplate RPM: 1,725 RPM
- Hz: 60 Hz
- Full Load Amps: 5.3 A
- RPM Range: 1,701-1,800
- Phase: Single
Specifications
| Part Number | D14B2N4Z |
| Brand | U.S. Motors |
| Motor Shaft Design | Flat |
| Shaft Dia. | 1/2 in |
| HP | 1/4 hp |
| Frame | 48Z |
| Inverter Rated | Not Inverter Rated |
| Overall Length | 9 3/4 in |
| Length Less Shaft | 7 3/8 in |
| Shaft Length | 2 3/8 in |
| Item | General Purpose Motor |
| Nameplate RPM | 1,725 RPM |
| Motor Thermal Protection | None |
| Hz | 60 Hz |
| Motor Bearings | Ball |
| Motor Enclosure Design | Open Drip Proof |
| Full Load Amps | 5.3 A |
| RPM Range | 1,701-1,800 |
| Standards | CSA Certified, UL Recognized |
| Motor Mounting Position | Horizontal |
| Phase | Single |
| Nominal Efficiency | 56.6 % |
| Voltage Compatibility | 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC |
| Motor Service Factor | 1.35 |
| Voltage | 115V AC |
| Duty | Continuous |
| Max. Ambient Temp. | 40 Degrees C |
| CC Number | CC030A |
| Motor Shaft Rotation | CW/CCW |
| No. of Speeds | 1 |
| Motor Design | Split-Phase |
| Motor Mounting Type | Rigid Base |
| Ins. Class | B |
| RPM Group | 1701-1800 |
| Motor Frame Material | Steel |
| Motor Application | General Purpose |
| Usable @ 200V | Not Usable at 200V |
| Usable @ 208V | Not Usable at 208V |
| Weight | 14.6 lb |
| Duty Cycle | Continuous |
Description
The U.S. Motors D14B2N4Z is a 1/4 hp, 115V AC, 60 Hz split-phase general purpose motor with a 48Z frame and 1,725 RPM nameplate speed. This open drip proof motor draws 5.3 full load amps and is CSA Certified and UL Recognized.
