- Reset Pressure Band: 3 +/-0.5 to 8 psig
- Mounting Hole Diameter: 3/16 in
- Air Inlet Size: 1/4 in
- Material of Construction: ABS
- Max. Signal Pressure (In. WC): 6
- Operating Temp. Limit (F): 40 to 120 Degrees F
Specifications
| Part Number | CSC-2004 |
| Brand | Kmc Controls |
| Type | Sub Master |
| Thermostat Required for Cooling | Reverse Acting |
| Reset Pressure Band | 3 +/-0.5 to 8 psig |
| Setpoint Range Minimum (In. WC) | 0 to 1 |
| Color | Gray |
| Mounting Hole Dia. | 3/16 in |
| Mounting Hole Diameter | 3/16 in |
| Air Inlet Size | 1/4 in |
| Item | Reset Volume Controller |
| Output Sensitivity (In. WC) | 5 PSI / 0.02 in wc |
| Material of Construction | ABS |
| Max. Signal Pressure (In. WC) | 6 |
| Connection Ports | Push On Fittings For 1/4 in OD Tubing |
| Operating Temp. Limit (F) | 40 to 120 Degrees F |
| Includes | Mounting Bracket |
| Main Air Pressure (PSIG) | 15 to 30 psig |
| Features | Adjustable Min Max Air Flow |
| Setpoint Range Maximum (In. WC) | 0 to 1 |
| Air Consumption | 14.4 scim |
| Output Capability | 0 to Supply Pressure |
| Control Type | RA |
| Accessories | HFO-0006/SSS-1000 Series Flow Sensors, 4DEA3, 4DEA4, 4DEA5, 4DEA6 |
| Thermostat Required for Heating | Direct Acting |
| Standards | RoHS Compliant |
| Application | Variable Air Volume |
| Output Pressure Capability | 0 to Supply Pressure |
| Air Inlet Type | Push-On |
| Controller Type | Sub Master |
| Maximum Air Pressure | 30 psi |
| Series | 2000 |
| Maximum Operating Temperature | 120 Degrees F |
| Minimum Operating Temperature | 40 Degrees F |
| Housing Material | ABS |
| Dial Face Type | Paper Label |
| Minimum Air Pressure | 15 psi |
| Damper Action | Normally Closed |
| Weight | 0.47 lb |
| Output Sensitivity | 5 psi / 0.02 in wc |
| Minimum Setpoint Range Minimum | 0 to 1 in wc |
| Mounting Orientation | Horizontal, Vertical |
| Reset Start Point Maximum Setting | 8 psi |
| Signal Pressure - Maximum | 6 in wc |
| Product Type | Reset Volume Controller |
| Reset Start Point Factory Setting | 3 psi |
| Housing Color | Gray |
| Reset Start Point Minimum Setting | 3 psi |
| Maximum Setpoint Range | Min to 1 in wc |
| Controller Action | Reverse Acting |
Description
The Kmc Controls CSC-2004 is a Reset Volume Controller, a type of Sub Master part for HVAC systems. This controller regulates signal pressure, with a reset pressure band of 3 +/-0.5 to 8 psig and a maximum signal pressure of 6 inches of water column. It is constructed from ABS and includes a mounting bracket.
