- Main Air Pressure (PSIG): 15 to 30 psig
- Reset Pressure Band: 8 +/-0.5 to 13 psig
- Air Inlet Size: 1/4 in
- Mounting Hole Diameter: 3/16 in
- Operating Temp. Limit (F): 40 to 120 Degrees F
- Material of Construction: ABS
Specifications
| Part Number | CSC-2001 |
| Brand | Kmc Controls |
| Type | Sub Master |
| Thermostat Required for Heating | Reverse Acting |
| Main Air Pressure (PSIG) | 15 to 30 psig |
| Control Type | DA |
| Reset Pressure Band | 8 +/-0.5 to 13 psig |
| Mounting Hole Dia. | 3/16 in |
| Air Inlet Size | 1/4 in |
| Mounting Hole Diameter | 3/16 in |
| Item | Reset Volume Controller |
| Includes | Mounting Bracket |
| Thermostat Required for Cooling | Direct Acting |
| Air Consumption | 14.4 scim |
| Accessories | HFO-0006/SSS-1000 Series Flow Sensors, 4DEA3, 4DEA4, 4DEA5, 4DEA6 |
| Features | Adjustable Min Max Air Flow |
| Setpoint Range Maximum (In. WC) | Min + 1 |
| Output Sensitivity (In. WC) | 5 PSI / 0.02 in wc |
| Output Capability | 0 to Supply Pressure |
| Operating Temp. Limit (F) | 40 to 120 Degrees F |
| Connection Ports | Push On Fittings For 1/4 in OD Tubing |
| Material of Construction | ABS |
| Max. Signal Pressure (In. WC) | 6 |
| Color | Beige |
| Setpoint Range Minimum (In. WC) | 0 to 1 |
| Standards | RoHS Compliant |
| Application | Variable Air Volume |
| Air Inlet Type | Push-On |
| Maximum Setpoint Range | Min + 1 in wc |
| Output Pressure Capability | 0 to Supply Pressure |
| Mounting Orientation | Horizontal with Dial Up |
| Minimum Setpoint Range Minimum | 0 to 1 in wc |
| Weight | 0.47 lb |
| Maximum Operating Temperature | 120 Degrees F |
| Reset Start Point Factory Setting | 8 psi |
| Reset Start Point Minimum Setting | 8 psi |
| Signal Pressure - Maximum | 6 in wc |
| Product Type | Reset Volume Controller |
| Dial Face Type | 0-10 Molded Plastic |
| Controller Type | Sub Master |
| Housing Color | Beige |
| Minimum Air Pressure | 15 psi |
| Reset Start Point Maximum Setting | 13 psi |
| Series | 2000 |
| Housing Material | ABS |
| Damper Action | Normally Open |
| Minimum Operating Temperature | 40 Degrees F |
| Maximum Air Pressure | 30 psi |
| Output Sensitivity | 5 psi / 0.02 in wc |
| Controller Action | Direct Acting |
Description
The Kmc Controls CSC-2001 is a Reset Volume Controller for VAV applications. This sub master controller operates with a main air pressure of 15 to 30 psig and a reset pressure band of 8 +/-0.5 to 13 psig, featuring direct acting (DA) control and an adjustable minimum and maximum air flow. It includes a mounting bracket and operates within a temperature limit of 40 to 120 degrees F.
