- HP: 5 hp
- Nameplate RPM: 3,450 RPM
- Voltage: 230V AC
- RPM Range: 3,001-3,600
- Max. Ambient Temp.: 40 Degrees C
- Phase: Single
Specifications
| Part Number | CP1502L |
| Brand | Century |
| HP | 5 hp |
| Nameplate RPM | 3,450 RPM |
| Shaft Dia. | 7/8 in |
| Voltage | 230V AC |
| Frame | Y56HZ |
| Length Less Shaft | 11 3/4 in |
| Shaft Length | 2 5/16 in |
| Overall Length | 14 1/16 in |
| Item | Air Compressor Motor |
| Motor Design | Capacitor-Start |
| Motor Enclosure Design | Open Drip Proof |
| Motor Bearings | Ball |
| Motor Application | Air Compressor |
| RPM Range | 3,001-3,600 |
| Max. Ambient Temp. | 40 Degrees C |
| Phase | Single |
| Ins. Class | B |
| Standards | CSA, UL Listed |
| Motor Service Factor | 1 |
| Full Load Amps | 19.7 A |
| Motor Mounting Type | Rigid Base |
| Voltage Compatibility | 230V AC |
| Hz | 60 Hz |
| Motor Thermal Protection | Manual |
| Motor Mounting Position | Horizontal |
| Motor Shaft Rotation | CW/CCW |
| Motor Shaft Design | Keyed |
| Motor Frame Material | Steel |
| Duty Cycle | Continuous |
| Usable @ 208V | Not Usable at 208V |
| No. of Speeds | 1 |
| Usable @ 200V | Not Usable at 200V |
| Weight | 44 lb |
Description
The Century CP1502L is a 5 hp air compressor motor with a nameplate speed of 3,450 RPM. This single-phase, capacitor-start unit operates on 230V AC at 60 Hz and features a Y56HZ steel frame with a rigid base for horizontal mounting. It has a 7/8-inch keyed shaft, ball bearings, an open drip proof enclosure, and a continuous duty cycle.
