CP1302L Century Air Compressor Motor 3 HP, 3450 RPM, 208–230V, Single Phase

SKU: CP1302L
Your Price:
$574.90
Shipping: $299.00 freight, curbside delivery with liftgate. Dispatch timing varies by product and supplier.US only. The exact cost is confirmed at checkout.
Add to wishlist
Checkout Secure

Great reasons to buy from us:

  • Image of Quality Guaranteed

    Quality

    Quality Guaranteed
  • Image of Fast Shipping

    Free shipping

    Fast Shipping
  • Image of Great Value

    Fast Shipping

    Great Value
  • Image of Secure Online Ordering

    Free shipping

    Secure Online Ordering
  • HP: 3
  • Nameplate RPM: 3,450 RPM
  • Voltage: 208-230V AC
  • RPM Range: 3,001-3,600
  • Full Load Amps: 13.1 to 12.3 A
  • Max. Ambient Temp.: 40 Degrees C

Specifications

Part Number CP1302L
Brand Century
HP 3
Nameplate RPM 3,450 RPM
Shaft Dia. 5/8 in
Voltage 208-230V AC
Frame 56
Overall Length 12 11/16 in
Length Less Shaft 10 3/4 in
Shaft Length 1 15/16 in
Item Air Compressor Motor
Motor Design Capacitor-Start
Motor Enclosure Design Open Drip Proof
RPM Range 3,001-3,600
Full Load Amps 13.1 to 12.3 A
Motor Mounting Position Horizontal
Max. Ambient Temp. 40 Degrees C
Motor Shaft Rotation CW/CCW
Ins. Class B
Motor Thermal Protection Manual
Motor Mounting Type Rigid Base
Motor Application Air Compressor
Hz 60 Hz
Voltage Compatibility 208V AC, 230V AC
Motor Service Factor 1
Motor Bearings Ball
Standards CSA, UL Listed
Phase Single
Duty Cycle Continuous
Motor Shaft Design Keyed
Usable @ 208V Usable at 208V
Weight 33 lb
No. of Speeds 1
Motor Frame Material Steel
Usable @ 200V Not Usable at 200V

Description

The Century CP1302L is a 3 HP air compressor motor with a nameplate speed of 3,450 RPM and a voltage rating of 208–230V AC, single phase. It features a 56 steel frame, capacitor-start design, open drip proof enclosure, and a keyed shaft with a 5/8-inch diameter. The motor has a rigid base for horizontal mounting, ball bearings, a continuous duty cycle, and a full load amp range of 13.1 to 12.3 A.
