- Amps: 70 A
- AC Voltage Rating: 525V AC
- Max. AIR Rating: 25kA at 277/408V AC
- For Use With: Electrical Distribution Equipment
- Industrial Control: Panels
- Series: BDA
Specifications
| Part Number | BDA36070 |
| Brand | Square D |
| Item | Molded Case Circuit Breaker |
| Amps | 70 A |
| AC Voltage Rating | 525V AC |
| Max. AIR Rating | 25kA at 277/408V AC |
| For Use With | Electrical Distribution Equipment |
| Industrial Control | Panels |
| Series | BDA |
| Circuit Breaker Type | Standard |
| Number of Poles | 3 |
| DC Voltage Rating | Not Rated |
| Terminal Connection | Al Mechanical Lug OFF End |
| End | I-Line ON |
| Trip Type | Thermal Magnetic |
| Phase | Three |
| Instantaneous Trip | Fixed |
| Phase Connection | ABC |
| Frame Size | 125A/BD |
| Circuit Breaker Mounting Style | I-Line |
| Height | 5.39 in |
| UPC | 785901010883 |
Description
The Square D BDA36070 is a molded case circuit breaker from the POWERPACT B Series. This 3-pole, 70 A unit is rated for 525V AC with a maximum AIR rating of 25kA at 277/408V AC. It features thermal magnetic trip protection, a fixed instantaneous trip, and an I-Line mounting style.
Confirm the part number against your existing unit or equipment before ordering to ensure correct fit.
