- Coil Voltage: 120V AC
- NEMA Size: 00
- HP @ 3 Phase - 575V: 2 hp
- HP @ 1 Phase - 230V: 1 hp
- Maximum Voltage Rating: 600V AC
- NEMA Enclosure Rating: No Enclosure
Specifications
| Part Number | AN19AN0A5E005 |
| Brand | Eaton |
| Auxiliary Contact Form | 1NO |
| Coil Voltage | 120V AC |
| Number of Poles | 3 |
| Reversing Capability | Non-Reversing |
| Number of Auxillary Contacts | 1 |
| NEMA Size | 00 |
| Product Length/Depth | 4.9 in |
| Overall Depth | 4.9 in |
| Overall Width | 1.97 in |
| Overall Height | 6.6 in |
| Item | NEMA Magnetic Motor Starter |
| Standards | CE, CSA, UL Listed |
| Includes | Class 20 Solid State Ambient-Compensated Overload Relay and Instantaneous Magnetic Trip Mechanism |
| HP @ 3 Phase - 575V | 2 hp |
| HP @ 1 Phase - 230V | 1 hp |
| Enclosure Type | Open |
| Weight | 2.1 lb |
| Special Features | With C440 EOLR standard feature set, SEL reset, SEL class (10a, 10, 20, 30) |
| Product Name | Eaton Freedom NEMA motor control starter |
| Configuration | Non-reversing |
| Full Load Current Range | 1-5 A |
| Overload Relay | C440 electronic |
| Maximum Voltage Rating | 600V AC |
| NEMA Enclosure Rating | No Enclosure |
| Frequency | 50/60 Hz |
| Mounting Postion | Horizontal |
| Horsepower @ Three Phase - 600V AC | 2 hp |
| Maximum Overload Relay Current Setting | 5:00 AM |
| Minimum Overload Relay Current Setting | 1 A |
| Trip Class | 10A/10/20/30 |
| Horsepower @ Three Phase - 208V AC | 1 1/2 hp |
| Includes Auxiliary Contacts | Yes |
| Mounting Style | Surface |
| Operator | None |
| Starter Style | NEMA |
| Horsepower @ Three Phase - 240V AC | 1 1/2 hp |
| Series | Freedom |
| Horsepower @ Single Phase - 240V AC | 1 hp |
| Phase | Three |
| Current AC | 9:00 AM |
| Auxiliary Contact Module Capacity | 6 |
| Horsepower @ Single Phase - 120V AC | 1/3 hp |
| Overload Protection Type | Electronic |
| Horsepower @ Three Phase - 480V AC | 2 hp |
| Full Load Current - Inductive | 5 A |
| Terminal Connection Type | Screw |
Description
The Eaton AN19AN0A5E005 is a NEMA Magnetic Motor Starter, a non-reversing device that controls the starting and stopping of an electric motor. It operates on 120V AC and includes a Class 20 solid state ambient-compensated overload relay and an instantaneous magnetic trip mechanism. This NEMA Size 00 starter is CE, CSA, and UL Listed, and is rated for 2 hp at 575V three-phase or 1 hp at 230V single-phase.
