- Housing Material: Cast iron
- HP: 1/2
- Hz: 60 Hz
- Diameter: 10-1/8"
- Max. Diameter Solids: 1/2 in
- Solids Diameter - Maximum: 1/2 in
Specifications
| Part Number | 98-0002 |
| Brand | Zoeller |
| Cord Length | 15 ft |
| Discharge NPT | 1-1/2" F |
| Housing Material | Cast iron |
| HP | 1/2 |
| Hz | 60 Hz |
| Height | 12" |
| Manufacturers Warranty Length | 3 yr |
| Diameter | 10-1/8" |
| Max. Dia. Solids | 1/2" |
| Max. Diameter Solids | 1/2 in |
| Cord Length - Pumps | 15 ft. |
| Min. Sump Pit Dia. | 18 in |
| Overall Height | 12 in |
| Body Dia. | 10 1/8 in |
| Discharge Dia. | 1 1/2 in |
| Solids Diameter - Maximum | 1/2 in |
| Discharge Diameter | 1 1/2 in |
| Body Diameter | 10 1/8 in |
| Sump Pit Diameter - Minimum | 18 in |
| Impeller Material | Plastic |
| Max. Head | 23 ft |
| Max. Temp. | 130 Degrees F |
| Motor RPM | 1550 |
| Motor Type | Permanent Split Capacitor |
| Shaft Seal | Carbon/Ceramic |
| Voltage | 115V |
| Phase | Single |
| Thermal Protection | Manual |
| Gauge/Conductor | 18/3 |
| Pump Body Material | Cast Iron |
| Switch Type | None |
| Amps | 9.4 A |
| GPM of Water @ 15 Ft. of Head | 45 |
| Base Material | Engineered Thermoplastic |
| GPM of Water @ 20 Ft. of Head | 25 |
| GPM of Water @ 10 Ft. of Head | 61 |
| Max. Liquid Temp. | 130 Degrees F |
| Voltage - Pumps | 120VAC |
| NEC Cord Designation | SJOW |
| Amps - Pumps | 9.40 |
| Item - Sump Pumps | Submersible Sump Pump |
| GPM of Water @ 5 Ft. of Head | 72 |
| Item | Submersible Sump Pump |
| Impeller Material - Pumps | Polypropylene |
| Alarm Included | No |
| Switch Type - Pumps | No Switch Included |
| Shaft Seal Material - Pumps | Carbon, Ceramic |
| Max. Head - Pumps | 23 ft. |
| Alarm | No |
| Mechanical Seal | CRB/CMC |
| Switch Electrical Connection | No Switch Included |
| RPM | 1,550 RPM |
| Flow Rate @ 15 Ft. of Head | 45 gpm |
| Discharge | 1 1/2 in FNPT |
| Switch Actuation | No Switch Included |
| Flow Rate @ 20 Ft. of Head | 25 gpm |
| Discharge Gender | Female |
| Flow Rate @ 10 Ft. of Head | 61 gpm |
| Rated Voltage | 115V AC |
| Body Material | Cast Iron |
| Duty Cycle | Continuous |
| Discharge Standard | NPT |
| Flow Rate @ 5 Ft. of Head | 72 gpm |
| Current | 9.4 A |
| Shaft Seal Type | Single Mechanical |
| Horsepower | 1/2 hp |
| Flow Rate @ 40 ft of Head | 0 gpm |
| Shaft Seal Material | Carbon/Ceramic |
| Hazardous Location Class | Not Rated |
| Liquid Temperature - Maximum | 130 Degrees F |
| Motor Housing Material | Cast Iron |
| Feet of Head - Maximum | 23 ft |
| Volute Material | Plastic |
| Power Source | Corded Electric |
| Includes Alarm | No Alarm Included |
| Flow Rate @ 10 ft of Head | 61 gpm |
| For Media Type | Effluent Water |
| Flow Rate @ 20 ft of Head | 25 gpm |
| Rotation Speed - Maximum | 1,550 RPM |
| Requires Control Panel | Control Panel Required |
| Impeller Design | Vortex |
Description
The Zoeller 98-0002 is a 1/2 HP condensate pump with a cast-iron housing and a plastic impeller. This pump moves collected condensate from HVAC equipment. It operates on 115V at 60 Hz with a permanent split capacitor motor running at 1550 RPM, and handles fluid temperatures up to 130 degrees Fahrenheit.
