- Coil Voltage: 120V AC
- HP @ 240V: 1/2 hp
- HP @ 120V: 1/3 hp
- Contact Material: Silver Alloy
- Horsepower @ 120V AC: 1/3 hp
- Horsepower @ 240V AC: 1/2 hp
Specifications
| Part Number | 8501KPR12P14V20 |
| Brand | Schneider Electric |
| CAD Drawing | 2D Drawing (.pdf) |
| Mounting Style | Socket |
| Electrical Connection | Pin |
| Base Shape | Octal |
| Number of Pins | 8 |
| Coil Voltage | 120V AC |
| Overall Height - Relay | 2.6 in |
| Overall Depth | 2.7 in |
| Body Width | 1.4 in |
| Body Height | 1.4 in |
| Body Depth | 2.1 in |
| Item | General Purpose Relay |
| Current Rating | 10 A |
| Contact Form | DPDT |
| Contact Rating (AC) | 10 A @ 277V |
| Contact Rating (DC) | 10 A @ 28V |
| Socket | Mfr. No. 8501NR51 or 8501NR52 |
| Standards | CE Certified, CSA Certified, UL Listed |
| HP @ 240V | 1/2 hp |
| HP @ 120V | 1/3 hp |
| Socket Code | A |
| Status Indicator | LED Indicator, Mechanical Flag |
| Power Consumption - Relay | 3 VA |
| Contact Material | Silver Alloy |
| Green Environmental Attribute | RoHS 2011/65/EU Compliant |
| Features | Indicator Light Relay Energised LED |
| Horsepower @ 120V AC | 1/3 hp |
| Motor Rated | Yes |
| Series | Square D 8501K Series |
| Sealing | Enclosed |
| Horsepower @ 240V AC | 1/2 hp |
| Compatible with Manufacturer Model Number | 8501NR51, 8501NR52 |
| Push-To-Test Method | No Button |
| Maximum Switching Voltage | 300V AC, 30V DC |
| Maximum Operating Temperature | 131 Degrees F |
| Pin Shape | Round |
| Response Time | 20 msec |
| Power Consumption | 3 VA |
| Minimum Operating Temperature | -40 Degrees F |
| Compatible Manufacturer Part Number | 8501NR51, 8501NR52 |
| Compatible Manufacturer Model Number | 8501NR51, 8501NR52 |
| Operating Time | 20 ms - pick-up || 20 ms - drop-out |
| Switching Voltage | 300 V AC; 30 V DC |
| CAD Available | Yes |
Description
The Schneider Electric 8501KPR12P14V20 is a general purpose relay with a 120V AC coil and DPDT (double-pole double-throw) contacts rated at 10 A. This relay switches electrical loads in control circuits, with contact ratings of 10 A at 277V AC and 10 A at 28V DC, and a horsepower rating of 1/2 hp at 240V. It is CE Certified, CSA Certified, and UL Listed, and connects via an 8-pin octal socket.
