- Voltage: 120V AC
- Amps: 40 A
- Enclosure Material: Steel
- Horsepower @ 240V - Maximum: 2 hp
- NEMA Enclosure Rating: 1
- Horsepower @ 120V - Maximum: 2 hp
Specifications
| Part Number | 8141-00 |
| Brand | Nor-lake |
| Voltage | 120V AC |
| Amps | 40 A |
| Contact Type | 1 NO/2 NC |
| Max. On/Off Cycles | 1 to 6 Per Day, Minimum of 4 Hours Between Successive Defrost Cycles |
| Defrost Time (Minutes) | 4 to 110, 2 min Increments |
| Item | Defrost Control Timer |
| Enclosure Material | Steel |
| Termination Type | Temperature Or Pressure |
| Defrost Initiation | Time |
| Series Application | Electric Heat, Hot Gas or Compressor Shutdown |
| Initiation/Termination Type | Time / Temperature or Pressure |
| Switch Arrangements for Contacts 3-N | Closed |
| Agency Approvals | UL Listed|UL Recognized |
| Switch Arrangement for Contacts 1-3 | Open |
| Electrical Rating | 120V AC, 60 Hz|120V AC, 50 Hz |
| Comments | Bracket available & 50 Hz |
| Switch Arrangement for Contacts 2-4 | Closed |
| Enclosure | Heavy Duty Steel |
| Switch Rating | 40 Amps, 2HP, 690 VA, 120-240V AC |
| Defrost Time - Maximum | 110 min |
| Horsepower @ 240V - Maximum | 2 hp |
| NEMA Enclosure Rating | 1 |
| Series | 8000 |
| Current Rating - Maximum | 40 A |
| On/Off Cycles - Maximum | 6 |
| Horsepower @ 120V - Maximum | 2 hp |
| Display Type | Mechanical |
| Defrost Time - Minimum | 4 min |
| Standards | UL Listed |
| AC Voltage Rating | 120V AC |
| Initiation | Time |
| Contact Form | SPDT-NO/2NC |
| Termination | Pressure or Temperature |
Description
The Nor-Lake 8141-00 is a defrost control timer with 1 NO/2 NC contacts. This timer initiates and terminates defrost cycles based on time, temperature, or pressure. It operates at 120V AC and 40 A, with a steel enclosure, and is used in electric heat, hot gas, or compressor shutdown series applications.
