- 1st Layer Load Capacity: 1,000 lb
- Motor HP: 0.8 hp
- Rope Material: Wire
- Included Line Diameter: 3/10 in
- Recommended Line Diameter: 1/5 in
- Voltage Rating: 115V AC
Specifications
| Part Number | 80010 |
| Brand | Viega |
| Electric Winch Item | Electric Winch |
| Winch Type | Pulling |
| 1st Layer Load Capacity | 1,000 lb |
| Motor HP | 0.8 hp |
| Rope Material | Wire |
| Included Rope Length | 43 ft |
| Overall Height | 6 1/4 in |
| Overall Length | 15 7/16 in |
| Manufacturers Warranty Length | 1 yr |
| Overall Width | 6 in |
| Control Pendant Cord Length | 8 ft |
| Included Rope Dia. | 3/16 in |
| Included Line Diameter | 3/10 in |
| Line Length | 43 ft |
| Controller Cord Length | 8 ft |
| Mfr. Warranty Length | 1 yr Limited |
| Recommended Line Diameter | 1/5 in |
| Voltage Rating | 115V AC |
| 1st Layer Line Speed | 5.5 fpm |
| Full Load Amps | 6.5 A |
| Winch Gear Type | Differential Planetary |
| Item | Electric Winch |
| Clutch Release | Yes |
| Series | 1000 Series |
| Mechanical Brake | No |
| Full Load Line Speed | 6.6 fpm |
| Free Spooling Clutch Type | Pull and Turn |
| Winch Gear Ratio | 261:1 |
| No Load Line Speed | 9.8 fpm |
| 1st Layer Line Pull | 1000 lb. |
| Pulley Block | No |
| Gear Type | Planetary |
| Gear Ratio | 261:1 |
| Clutch Type | Free Spooling Clutch |
| Body Material | Steel |
| Includes Brake | Brake Included |
| Included Components | Clutch Release, Hardware |
| Product Type | Electric Winch |
| Color | Gray |
| Controls | Pendant |
| Motor Horsepower | 3/4 hp |
| Operation | Pulling |
| Includes | Winch, Remote Control, Mounting Bolts |
| Compatible Line | Wire Rope |
| Maximum Pulling Capacity | 1,000 lb |
| Maximum Current | 6 A |
| Control Type | Manual Handle |
| Max Drum Capacity per Line Dia | 43 ft per 3/16 Inch |
| Operating Voltage | 120V AC |
| Voltage | 120V AC |
Description
The Viega 80010 is an electric winch of the pulling type. It operates on 115V AC with a 0.8 hp motor and a 1st layer load capacity of 1,000 lb, featuring a wire rope and a differential planetary gear system.
