- Amps AC: 1.5 A
- Voltage: 24
- Minimum Operating Temperature: -40 Degrees F
- Input Voltage: 24V AC
- Control Voltage: 24V AC
- Frequency: 50/60 Hz
Specifications
| Part Number | 780-002 |
| Brand | Robertshaw |
| Type | Lockout, 1 Rod or 2 Rod Sensing |
| Retries | 3 |
| Control Volts | 24 V |
| Gas Type | LP |
| Amps AC | 1.5 A |
| Item | Ignition Control |
| Electrical Connections | 1/4 in Spades and Molex plug |
| Includes | 780-845 Module, Mounting Kit, Wiring Harness |
| For Use With | Residential, Commercial Heating Equipment, Universal Replacement Spark Control Designed For Maximum Compatibility |
| Operation Description | Lockout Feature To Shut Off All Gas To The Furnace, Should Pilot Ignition Fail To Occur After A Predetermined Time Period. The 780-002 Provides 3 Tries For Ignition, Each Ignition Period Is 90 Seconds Followed By A 6 Minute Time Delay Between Ignition Attempts. After 3 Tries If No Pilot Flame Is Sensed, Unit Goes Into Lockout And Must Be Reset At The Thermostat. |
| Prepurge Time (Sec.) | 360 sec |
| Voltage | 24 |
| Electrical Ratings | 24 |
| Standards | cCSAus |
| Product Type | Ignition Control |
| Minimum Operating Temperature | -40 Degrees F |
| For Fuel Type | LP |
| Compatible with Series | Universal |
| Maximum Input Current | 1.5 A |
| Thermostat Anticipator Setting | Thermostat Anticipator |
| Number of Retries | 3 |
| Compatible with Brand | See full list of Compatible with Brand Airflow,Alco Food,Binet,Bradford-White,Cabell,Carrier,Chamberlain,Ed PAC/AC,Edison,Eisco Limited,Electro-Home,Electro-Therm,Elixier,Elkay,Ellis & Watts,Elmet,Embassy Industries,General Steel Wares,Honeywell,International,Johnson Controls,Johnstone Supply,Kool-Fire,Leemco,Lennox,Robertshaw,Uni-Line,Westward |
| Input Voltage | 24V AC |
| Series | 780 |
| Flame Sensor Current Output | 0.7 mA |
| Replacement Type | Universal |
| Lock Out Time | 1 min |
| Pre-Purge Time | 5 min |
| Control Voltage | 24V AC |
| Frequency | 50/60 Hz |
| Electrical Connection Type | 1/4 in Spade Terminals, Molex Plug |
| Ignition Cycle Time | 60 seconds |
| Maximum Operating Temperature | 175 Degrees F |
| Main Valve Current Output | 1.5 A |
Description
The Robertshaw 780-002 is a universal replacement ignition control module for intermittent pilot lockout systems. This module controls the ignition sequence, sensing flame via 1 or 2 rods, and operates on 24 V with a 1.5 A rating for LP gas. It is designed for maximum compatibility with residential and commercial heating equipment and includes the 780-845 module, mounting kit, and wiring harness with 1/4 in spades and a Molex plug.
