- Body Material: Bronze
- Temp. Range: 33 Degrees F to 180 Degrees F
- Size: 1 in
- Connection Size - Side 1: 1 in
- Connection Size - Side 2: 1 in
- Nominal Valve Size: 1 in
Specifications
| Part Number | 4A-205-A2F |
| Brand | Apollo Valves |
| Body Material | Bronze |
| Temp. Range | 33 Degrees F to 180 Degrees F |
| Width | 3 1/4 in |
| Overall Height | 8 in |
| Connection | NPS |
| Size | 1 in |
| Height | 8 in |
| Length | 14 5/8 in |
| Overall Length | 14.63 in |
| Overall Width | 3.25 in |
| Connection Size - Side 1 | 1 in |
| Connection Size - Side 2 | 1 in |
| Check Valve Length | 9 1/2 in |
| Nominal Valve Size | 1 in |
| Item | Principle Backflow Assembly 1" |
| Includes | No Items |
| Standards | Build America Buy America (BABA) Act, Buy American Act (BAA) |
| Max. Temp. | 180 Degrees F |
| Spring Material | Stainless Steel |
| Flow | 76 gpm |
| Max. Pressure | 175 psi |
| Features | 5 Year Warranty, Corrosion Resistant, Internal Sensing Passage, Lead-Free, Low Head Pressure Loss, Maximum Protection against Back-Pressure/Back-Siphonage, Modular Captured Spring Relief Valve, Modular Check Valve Cartridges with Easily Replaced Parts, Reversible/Removable Chloramine-Resistant Silicone Seats, Standard with Full Port Ball Valves with Stainless Steel Handles, Threaded Testcock Protectors, Top Mounted Test Cocks |
| Compliance | ASSE 1013, AWWA C511, CSA B64.4, Federal Public Law 111-380, UL, ULC |
| Seat Material | Silicone |
| Includes Strainer | No Strainer |
| Cracking Pressure | 5 psi |
| Connection Gender - Side 1 | Female |
| Operating Temperature - Minimum | 33 Degrees F |
| Includes Flood Protection | No Flood Protection |
| Number of Test Ports | 4 |
| Manufacturer Warranty | 5 yr |
| Mounting Orientation | Horizontal |
| Check Mechanism Material | Glass-Filled PPO |
| Shut-Off Valve Included | Ball Valve |
| Includes Freeze Sensor | No Freeze Sensor |
| Connection Type - Side 1 | NPSM |
| For Media | Water |
| Connection Type - Side 2 | NPT |
| Maximum Pressure - Operating | 175 psi |
| Handle Material | Stainless Steel |
| Includes Atmospheric Vent | No Atmospheric Vent |
| Connection Gender - Side 2 | Female |
| Operating Temperature - Maximum | 180 Degrees F |
| Hazard Protection Level | High Health Hazard |
| Backflow Preventer Type | Reduced Pressure Assembly (RP) |
| Valve Series | 4A |
Description
The Apollo Valves 4A-205-A2F is a 1-inch Reduced Pressure Zone Backflow Preventer. This assembly prevents the reverse flow of contaminated water into the potable water supply by maintaining a zone of reduced pressure between two check valves. It is constructed with a bronze body and complies with the Build America Buy America (BABA) Act and the Buy American Act (BAA).
