- Air Connection Size: 1/8 in
- Max. Air Pressure: 30 psi
- Control Pressure - Maximum: 30 psi
- Stem Material: Stainless Steel
- Diaphragm Material: Rubber
- Operating Temperature - Maximum: 200 Degrees F
Specifications
| Part Number | 332-3011 |
| Brand | Century Motors |
| Operating PSI Range | 8 to 13 |
| Application | Air Valves, Dampers |
| Stroke | 4 in |
| Nominal Spring Range | 8 to 13 psi |
| Net Force Exerted @ 0 PSI | 144 lb |
| Width | 7 3/16 in |
| Height | 8 1/2 in |
| Length | 20 13/16 in |
| Air Connection Size | 1/8 in |
| Overall Depth | 20 13/16 in |
| Overall Width | 8 1/16 in |
| Overall Length | 8 13/16 in |
| Item | Pneumatic Damper Actuator |
| Includes | Positioning Relay |
| Mounting Type | Pivot |
| Max. Air Pressure | 30 psi |
| For Use With | Dampers or Air Valves |
| Net Force Exerted @ 18 PSI | 89 lb |
| Provides | Modulating or Two Position Control |
| Fire/Smoke Application | Not UL Recognized Components for Fire/Smoke Applications |
| Control Pressure - Maximum | 30 psi |
| Stem Material | Stainless Steel |
| Diaphragm Material | Rubber |
| Operating Temperature - Maximum | 200 Degrees F |
| Includes Positioner | Positioner Included |
| Installation Orientation | Versatile |
| Spring Range Maximum | 13 psi |
| Spring Range Minimum | 3 psi |
| Spring Material | Steel |
| Specific Valve Action | Spring Return Down |
| Air Connection Type | NPT |
| For Media | Air |
| Manufacturer Series | 331 |
| Force at 0 psi | 144 lbf |
| Actuator Type | Linear |
| Air Connection Gender | Female |
| Actuator Connection | Clevis, Pivot |
| Operating Temperature - Minimum | -20 Degrees F |
Description
The Century Motors 332-3011 is a pneumatic damper actuator. This actuator uses compressed air to open and close dampers or air valves, operating within an 8 to 13 psi range and a maximum air pressure of 30 psi. It includes a positioning relay and features a pivot mounting type with a 1/8 in air connection.
