- Process Connection Size: 1/8 in
- Nominal Dial Size: 4 in
- Gauge Nominal Dial Size: 4 in
- Differential Gauge Connection Size: 1/8 in
- Bolt Circle Diameter: 4.125 in
- Case Diameter: 4 3/4 in
Specifications
| Part Number | 2300-0 |
| Brand | Dwyer Instruments |
| Accuracy | +/-2.00% |
| Process Connection Type | NPT |
| Process Connection Size | 1/8 in |
| Series | 2000 |
| Process Connection Gender | Female |
| Nominal Dial Size | 4 in |
| Manufacturers Warranty Length | 1 yr |
| Gauge Nominal Dial Size | 4 in |
| Differential Gauge Connection Size | 1/8 in |
| Bolt Circle Diameter | 4.125 in |
| Manufacturer Warranty Length | 5 yr |
| Case Depth | 1.687 in |
| Case Diameter | 4 3/4 in |
| Item | Differential Pressure Gauge |
| Application | Flow Measurement, Vacuum Applications, Clean Rooms, HVAC/R, Fan Pressure Indication, Filtration Monitoring |
| Process Connection Location | Back, Side |
| Housing Material | Die Cast Aluminum |
| Pressure Range | 0.25 to 0 to 0.25 in wc |
| Sensor Type | Diaphragm |
| Rated Total Pressure | -20 in Hg to 15 psi |
| Differential Pressure Range Value | -0.25 to 0 to 0.25 |
| Scale Type | Pressure |
| Basic Gauge Case Material | Metal |
| Gauge Accuracy | +/-2% |
| Differential Pressure Range Units | in wc |
| Includes | Instructions, Three Mounting Adapters with Screws, Two 1/8 in NPT Plugs, Two 1/8 in NPT to 3/16 in ID Rubber Tubing Adapters |
| Differential Pressure Range | 0.25 in to 0 to 0.25 in wc |
| Dial Material | Die Cast Aluminum |
| Body Material | Die Cast Aluminum |
| Differential Gauge Connection Type | FNPT |
| Gauge Primary Range Smallest Graduation | 0.01 |
| Gauge Connection Location | Back and Side |
| Gauge Operating Temp. Range | 20 Degrees to 140 Degrees F |
| Differential Pressure Gauge Type | Differential Pressure Gauge |
| Case Color | Gray |
| Case Material | Aluminum |
| Standards | EU Directive 2011/65/EU (RoHS II) |
| Pointer Material | Aluminum |
| Ambient Operating Temperature Range | 20 Degrees to 140 Degrees F |
| Mounting Orientation | Upright Only |
| Pressure Gauge Type | Differential Pressure Gauge |
| Panel Mount Characteristics | 3 L Dia Holes on E Dia Bolt Circle |
| Dial Color | White |
| Panel-Mountable | Yes |
| Blowout Safety Back | Yes |
| Bezel Material | Die Cast Aluminum |
| Hazardous Location Rating | Not Rated |
| Over-Pressure Limit | 1.72 bar |
| Case Shape | Round |
| Pointer Characteristics | Red Tipped Pointer of Heat Treated Aluminum Tubing is easy to see |
| Maximum Working Static Pressure | 80 psig |
| Compatible Process Media | Cleanroom |
| Dial Face Material | Plastic |
| Case Finish | Die Cast |
| Includes Vent Plug | Yes |
| Includes Mounting Hardware | Yes |
| Bezel Mounting Type | Flush |
| Accuracy Details | +/-2% (-HA model +/-1) of FS ( +/-3% (-HA +/-1.5%) on -0, -100PA, -125PA, -10MM and +/-4% (-HA +/-2%) on -00, -60PA, -6MM ranges), throughout range at 70 Degrees F (21.1 Degrees C). |
| Case Construction | Corrosion Resistant |
| Includes Calibration Certificate | No |
| Mounting Hardware Included | Flange |
| Adjustable Set Points | No |
| Non-Sparking | No |
| IP/NEMA Rating | IP67 |
| Removable Bezel | No |
| Sensor Material | Silicone Rubber |
| Gauge Case Material | Aluminum |
| Pressure Measurement - Maximum | 0.25 in wc |
| Operating Temperature - Minimum | 20 Degrees F |
| Operating Temperature - Maximum | 140 Degrees F |
| Number of Switches | 0 |
| Pressure Measurement - Minimum | -0.25 in wc |
| IP Rating | IP67 |
| Working Static Pressure - Maximum | 80 psig |
Description
The Dwyer Instruments 2300-0 is a Series 2000 Magnehelic Differential Pressure Gauge. This gauge measures the difference in pressure between two points, providing an indication of flow, vacuum, or filter status. It is used for flow measurement, vacuum applications, clean rooms, HVAC/R, fan pressure indication, and filtration monitoring, with 1/8 in female NPT process connections on the back and side.
