- Voltage: 115 V
- Phase: Single
- Inlet/Outlet Size: 3/4 in to 1 1/2 in
- Compatible Discharge Pipe Size: 3/4 in, 1 in, 1 1/4 in, 1 1/2 in
- Compatible Intake Pipe Size: 3/4 in, 1 in, 1 1/4 in, 1 1/2 in
- For Discharge Pipe Diameter: 3/4 in, 1 in, 1 1/4 in, 1 1/2 in
Specifications
| Part Number | 1BL032 |
| Brand | Bell & Gossett |
| Fits Brand | Multiple |
| For Use With | Universal |
| Voltage | 115 V |
| Phase | Single |
| Standards | cULus |
| Overall Length | 9-9/16 in |
| Inlet/Outlet Size | 3/4 in to 1 1/2 in |
| Compatible Discharge Pipe Size | 3/4 in, 1 in, 1 1/4 in, 1 1/2 in |
| Overall Width | 4-3/4 in |
| Compatible Intake Pipe Size | 3/4 in, 1 in, 1 1/4 in, 1 1/2 in |
| Face to Face Dimension | 6 3/8 in |
| Overall Height | 6-3/8 in |
| For Discharge Pipe Diameter | 3/4 in, 1 in, 1 1/4 in, 1 1/2 in |
| For Inlet Pipe Diameter | 3/4 in, 1 in, 1 1/4 in, 1 1/2 in |
| Item | Pump, 2/5 HP, 115V, 1 Phase, 3250 rpm, PL-55 CI |
| No. of Speeds | 1 |
| RPM | 3,250 RPM |
| Motor Design | Permanent Split Capacitor |
| HP | 2/5 |
| Motor Enclosure Design | Open Drip Proof |
| Application | Boosting |
| Impeller Material | PPS |
| Shaft Material | Stainless Steel |
| Housing Material - Pumps | Cast Iron |
| Max. GPM @ Head | 50 gpm @ 0 ft |
| Min. GPM @ Head | 0 gpm @ 52.5 ft |
| Mechanical Seal | Carbon on Silicon Carbide |
| Max. Temp. | 225 Degrees F |
| Connection Style | NPT/Flange |
| Maximum Flow Rate @ 10 Feet of Head | 44 gpm |
| Connection Type | Flange |
| Flange or Union Included | No |
| Maximum Flow Rate @ 15 Feet of Head | 40 gpm |
| Maximum Flow Rate @ 5 Feet of Head | 47 gpm |
| Maximum Flow Rate @ 25 Feet of Head | 32 gpm |
| Frequency | 60 Hz |
| Maximum Flow Rate @ 40 Feet of Head | 17 gpm |
| Pump Type | Standard |
| Maximum Flow Rate @ 20 Feet of Head | 37 gpm |
| Pipe to Flange or Union Connection Type | FNPT |
| Pump Housing Material | Cast Iron |
| For Use With Potable Systems | No |
| Maximum Flow Rate @ 50 Feet of Head | 3 gpm |
| Series | PL-55 |
| Maximum Media Temperature | 225 Degrees F |
| Horsepower | 2/5 hp |
| Maximum Flow Rate @ 30 Feet of Head | 27 gpm |
| Maximum RPM | 3,250 RPM |
| Rotor Type | Dry |
| Nameplate Voltage | 115V AC |
| Maximum Flow Rate @ 1 Feet of Head | 50 gpm |
| Maximum Feet of Head | 53 ft |
| For Low Lead Compliance Level | EX |
| Operating Pressure - Maximum | 150 psi |
| Pump Technology | Centrifugal |
| Electrical Connection Type | Hardwired |
| Mounting Orientation | Horizontal |
| Media Temperature - Minimum | 32 Degrees F |
| Feet of Head - Maximum | 53 ft |
| Includes Timer | No Timer Included |
| Includes Flange | No Flange Included |
| For Media Type | Clear Water |
| Pump Construction | 2-Piece |
| Includes Union | No Union Included |
| Operating Modes | Constant Pressure |
| Number of Flange Mounting Holes | 2 |
| Full Load Current | 4.7 A |
| Priming | Self-Priming |
| Connection Standard | Flange |
| Pump Casing Material | Cast Iron |
| Requires Dedicated Return Line | No Dedicated Return Line Required |
| Includes Volute | Volute Included |
| ANSI Flange Class | Class 150 |
| Revolutions Per Minute - Maximum | 3,250 RPM |
| Thermostat Included | No Thermostat Included |
| Flow Rate - Maximum | 35 gpm |
| Media Temperature - Maximum | 225 Degrees F |
| Number of Pump Heads | 1 |
Description
The Bell & Gossett 1BL032 is a condensate pump. This pump moves collected condensate from HVAC equipment to a drain. It is a 2/5 HP, 115 V, single-phase unit operating at 3,250 RPM and is cULus listed.
