- Voltage: 110 to 120V AC
- Pilot Pressure: 0 psi
- Pilot Port Size: 1/8 in NPT
- Pipe Size: 1/4 in
- Inlet Port Connection Size: 1/8 in
- Pilot Port Connection Size: 1/8 in
Specifications
| Part Number | 081SA400K000030 |
| Brand | Tylok |
| Body Style | Base-Mounted |
| Series | Mark 8 |
| Voltage | 110 to 120V AC |
| Valve Actuator / Return | Solenoid / Spring |
| Pilot Pressure | 0 psi |
| Overall Height | 3 1/32 in |
| Overall Width | 2 in |
| Pilot Port Size | 1/8 in NPT |
| Pipe Size | 1/4 in |
| Overall Length | 4 9/16 in |
| Inlet Port Connection Size | 1/8 in |
| Pilot Port Connection Size | 1/8 in |
| Item | Solenoid Air Control Valve |
| Coefficient of Volume | 1 |
| Vacuum Range | 0 to 28" Hg |
| Body Material | Steel |
| Override | Non-Locking |
| Actuator/Return | Solenoid/Spring |
| Electrical Connections | AC Plug-In w/Light |
| Valve Ways and Positions | 4-Way/2-Position |
| Standards | CSA Certified, UL Listed |
| Shifting Technology | Spool & Sleeve |
| NEMA Classification | NEMA 4 |
| Ambient Temp. Range | -10 Degrees to 115 Degrees F |
| Max. CFM - Valves | 46 cfm |
| Air Valve Type | 4-Way, 2-Position |
| Valve Vacuum Range | 0 to 28 in Hg |
| Operational Pressure Range | 0 to 150 psi |
| CFM | 46 |
| Pressure Range | 0 to 150 psi |
| Number of Positions | Two-Position |
| Number of Ways | Four-Way |
| Spool Material | Stainless Steel |
| Pilot Type | Internal Pilot, Remote Pilot |
| Electrical Connection Type | Plug-In |
| Duty Cycle | Continuous |
| Exhaust Port Connection Type | NPT |
| Actuator Type | Single Solenoid |
| Product Type | Solenoid Air Control Valve |
| Coefficient of Volume (Cv) | 0.8 |
| Includes Solenoid Coil | Solenoid Coil Included |
| Inlet Port Connection Gender | Female |
| Flow Rate - Maximum | 37 cfm |
| Valve Type | Spool |
| Inlet Port Connection Type | NPT |
| Poppet Material | Aluminum |
| Operating Temperature - Minimum | -10 Degrees F |
| Body Features | Single |
| Pilot Port Connection Gender | Female |
| Vacuum Rating | Vacuum Operable |
| Operating Temperature - Maximum | 115 Degrees F |
| Pilot Port Connection Type | NPT |
| Number of Ports | 5 |
| Return Action | Spring Return |
| Application | High Cycle-Rate Machines |
| Includes Mounting Hardware | Hardware Not Included |
| NEMA Rating | 4 |
| Exhaust Port Connection Gender | Female |
| For Media | Air, Inert Gas |
| Operating Pressure - Minimum | 14 psi |
| Operating Pressure - Maximum | 150 psi |
Description
The Tylok Mark 8 081SA400K000030 is a solenoid air control valve. This valve uses a solenoid and spring actuator to open and close, controlling the flow of air in a pneumatic system. It operates on 110 to 120V AC with a pilot pressure of 0 psi and is constructed with a steel body.
