- Mounting Hole Diameter: 1/4 in
- Temperature Control Range: 35 to 45 Degrees F
- Voltage: 120 to 240V AC
- Locked Rotor Amps @ 240V: 48 A
- Inductive Amps @ 120V: 16 A
- Locked Rotor Amps @ 120V: 96 A
Specifications
| Part Number | 134-1510 |
| Brand | Siemens |
| Compatible System Type | Cooling Coils, Hydronic Heating Coils, Pipes |
| Application | Heat or Cool |
| Switch Action | Open/Close on Rise |
| Switch Type | SPDT |
| Number of Cooling Stages | 1 |
| Sensing Bulb Dia. | 1/8 in |
| Capillary Length | 48 in |
| Bulb Length | 20 ft |
| Overall Height | 3-1/4 in |
| Overall Width | 2-3/8 in |
| Overall Depth | 2-3/8 in |
| Mounting Hole Diameter | 1/4 in |
| Number of Heating Stages | 1 |
| Temperature Control Range | 35 to 45 Degrees F |
| Control Type | Screwdriver |
| Voltage | 120 to 240V AC |
| Item | Line Voltage Mechanical Thermostat |
| Contact Rating Resistive @ 240V | 8 A |
| Enclosure Type | Galvanized/Steel |
| Number of Switches | 1 |
| Standards | CSA Certified, UL Listed |
| Includes | Mounting Bracket, Remote Sensing Bulb |
| Sensor Type | Hydraulic Capillary Bulb (Copper) |
| Locked Rotor Amps @ 240V | 48 A |
| Inductive Amps @ 120V | 16 A |
| Locked Rotor Amps @ 120V | 96 A |
| Inductive Amps @ 240V | 3 A, 8 A |
| For Use With | Supply Fan Motor and/or Outside Air Dampers |
| Thermostat Type | Freeze Protection Indoor Single-Stage Controls |
| Resistive Amps @ 208VAC | 9.2 A |
| Contact Rating Resistive @ 120V | 16 A |
| Features | Automatic Reset |
| Minimum Operating Temperature | 0 Degrees F |
| Differential Type | Fixed |
| Changeover Type | Automatic |
| Temperature Sensitivity | 15°F to 55°F |
| Frequency | 50 Hz, 60 Hz |
| Full Load Amps @ 240V AC | 8 A |
| Contact Rating | 120 to 240V AC |
| Maximum Operating Temperature | 140 Degrees F |
| Enclosure NEMA Rating | 1 |
| Temperature Scale | Fahrenheit/Celsius |
| Electrical Connection Type | Screw Terminal |
| Enclosure Color | Gray |
| Maximum Control Temperature | 45 Degrees F |
| Pilot Duty Rating | 125 VA @ 24 to 277V AC |
| Sensor Location | Remote |
| Full Load Amps @ 120V AC | 16 A |
| Number of Poles | 1 |
| Temperature Differential | 12 Degrees F |
| Minimum Control Temperature | 35 Degrees F |
| Mounting Direction | Horizontal |
| Housing Material | Steel |
| Programming Capability | Not Programmable |
Description
The Siemens 134-1510 is a line voltage mechanical thermostat. This type of thermostat controls heating or cooling by opening or closing an electrical circuit based on temperature, functioning here as a freezestat with a 35 to 45 degrees Fahrenheit range. It features a SPDT switch, operates at 120 to 240V AC with an 8 A resistive contact rating at 240V, and is compatible with cooling coils, hydronic heating coils, and pipes.
