- Coil Voltage: 120V AC
- NEMA Size: 0
- Horsepower @ Three Phase - 240V AC: 3 hp
- NEMA Enclosure Rating: No Enclosure
- Frequency: 50/60 Hz
- Minimum Operating Temperature: -4 Degrees F
Specifications
| Part Number | 14CUD32AF |
| Brand | Siemens |
| Auxiliary Contact Form | 1NO |
| Coil Voltage | 120V AC |
| Number of Poles | 3 |
| Reversing Capability | Non-Reversing |
| Terminal Connection Type | Screw |
| NEMA Size | 0 |
| Overall Width | 5.75 in |
| Overall Height | 7.44 in |
| Overall Depth | 3.75 in |
| Item | NEMA Magnetic Motor Starter |
| Number of Auxillary Contacts | 1 |
| Standards | CSA 22.2 No.14, NEMA ICS 2, UL 508 |
| Mounting Style | Surface |
| Horsepower @ Three Phase - 240V AC | 3 hp |
| Mounting Postion | Vertical |
| NEMA Enclosure Rating | No Enclosure |
| Frequency | 50/60 Hz |
| Minimum Operating Temperature | -4 Degrees F |
| Series | FVNR |
| Horsepower @ Three Phase - 208V AC | 3 hp |
| Trip Class | 5/10/20/30 |
| Overload Protection Type | Electronic |
| Mechanical Operating Durability | 10,000,000 |
| Includes Auxiliary Contacts | Yes |
| Horsepower @ Three Phase - 480V AC | 5 hp |
| Auxiliary Contact Module Capacity | 8 |
| Phase | Three |
| Maximum Operating Temperature | 104 Degrees F |
| Current AC | 18 A |
| Response Time | 10 to 24 msec (OFF-Delay Time), 19 to 29 msec (ON-Delay Time) |
| Maximum Voltage Rating | 600V AC |
| Minimum Overload Relay Current Setting | 5.5 A |
| Starter Style | NEMA |
| Maximum Overload Relay Current Setting | 22 A |
Description
The Siemens 14CUD32AF is a NEMA magnetic motor starter, a non-reversing device that uses an electromagnetic coil to safely start and stop an electric motor. This unit operates with a 120V AC coil voltage and is rated for 3 horsepower at 240V AC three-phase. It features three poles, a NEMA Size 0 rating, one normally open auxiliary contact, and screw-type terminal connections, complying with CSA 22.2 No.14, NEMA ICS 2, and UL 508 standards.
