- Full Load Amps: 45 A
- NEMA Contactor Size: 2
- NEMA Size: 2
- HP @ 3 Phase - 208V: 10 hp
- HP @ 3 Phase - 575V: 25 hp
- HP @ 3 Phase - 240V: 15 hp
Specifications
| Part Number | 40FP32AA |
| Brand | Siemens |
| Action | Non-Reversing |
| Full Load Amps | 45 A |
| Number of Poles | 3 |
| NEMA Contactor Size | 2 |
| Reversing | No |
| Height | 3.94 in |
| Width | 4.88 in |
| Depth | 4.25 in |
| NEMA Size | 2 |
| Overall Height | 4.88 in |
| Overall Depth | 4 in |
| Overall Width | 4.25 in |
| Item | NEMA Magnetic Contactor |
| Coil Volts | 110 to 120V AC/220 to 240V AC |
| HP @ 3 Phase - 208V | 10 hp |
| HP @ 3 Phase - 575V | 25 hp |
| HP @ 3 Phase - 240V | 15 hp |
| HP @ 3 Phase - 480V | 25 hp |
| Enclosure NEMA Rating | No Enclosure |
| Frame / Series / Class / Code | Class 40 |
| Auxiliary Contact Form | 1NO |
| Standards | REACH Art 33 |
| Hz | 60 |
| Series | 40 |
| Number of Normally Closed Main Contacts | 0 |
| Mechanical Operating Durability | 10,000,000 |
| Minimum Operating Temperature | -4 Degrees F |
| Terminal Connection Type | Screw Terminals |
| Horsepower @ Three Phase - 600V AC | 25 hp |
| NEMA Enclosure Rating | No Enclosure |
| Number of Auxillary Contacts | 1 |
| Contactor Style | NEMA |
| Horsepower @ Three Phase - 480V AC | 25 hp |
| Frequency | 60 Hz |
| Mounting Postion | Vertical |
| Full Load Current - Resistive | Not Rated |
| Full Load Current - Inductive | 45 A |
| Horsepower @ Three Phase - 208V AC | 10 hp |
| Maximum Voltage Rating | 600V AC |
| Mounting Style | Surface |
| Phase | Three |
| Horsepower @ Three Phase - 240V AC | 15 hp |
| Reversing Capability | Non-Reversing |
| Includes Auxiliary Contacts | Yes |
| Number of Normally Open Main Contacts | 3 |
| Maximum Operating Temperature | 104 Degrees F |
| Auxiliary Contact Module Capacity | 8 |
| Coil Voltage | 110-120/220-240V AC |
| Response Time | 10 to 24 msec (OFF-Delay Time), 19 to 29 msec (ON-Delay Time) |
| Embedded Surge Suppressor | No |
Description
The Siemens 40FP32AA is a NEMA Size 2 magnetic contactor. This non-reversing, three-pole device is rated for 45 full-load amps at 240 VAC and is used to switch electrical loads in HVAC and other equipment. It is rated for 10 hp at 208V, 15 hp at 240V, and 25 hp at both 480V and 575V three-phase.
