- HP: 1/3
- Nameplate RPM: 1,075
- Voltage: 208-230V AC
- Stack Size: 1 3/4 in
- RPM Range: 1,001-1,100
- Full Load Amps: 3.5 A
Specifications
| Part Number | 6986 |
| Brand | U.S. Motors |
| HP | 1/3 |
| Nameplate RPM | 1,075 |
| Voltage | 208-230V AC |
| Frame | 48 |
| Shaft Dia. | 1/2 in |
| Shaft Length | 4 in |
| Bolt Circle Dia. | 5 5/8 in |
| Length Less Shaft | 5 11/16 in |
| Overall Length | 9 11/16 in |
| Manufacturers Warranty Length | 1 yr |
| Body Dia. | 5 5/8 in |
| Stack Size | 1 3/4 in |
| Lead Length | 30 in |
| Motor Shaft Rotation | CWLE |
| RPM Range | 1,001-1,100 |
| Motor Design | Permanent Split Capacitor |
| No. of Speeds | 1 |
| Full Load Amps | 3.5 A |
| Voltage Compatibility | 208V AC, 230V AC |
| Motor Shaft Design | Keyed |
| Phase | Single |
| Motor Bearings | Ball |
| Motor Thermal Protection | Auto |
| Motor Mounting Type | Resilient Base |
| Item | HVAC Motor |
| Motor Sub Application | Condenser Fan |
| Hz | 60/50 Hz |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Enclosure Design | Totally Enclosed Air-Over |
| Ins. Class | B |
| Capacitor Required | Included |
| Motor Mounting Position | Horizontal |
| Motor Application | HVAC/R |
| Duty | Continuous |
| Usable @ 208V | Yes |
| Standards | CE certified, CSA Group, ISO9001:2015 Certified, UL LLC |
| Number of Shafts | 1 |
| Usable @ 200V | No |
| Nominal Efficiency | 68.9 % |
| Weight | 14.9 lb |
| Extended Thru-Bolts | Yes |
| Duty Cycle | Continuous |
| Conduit Box Position | F1 |
| RPM @ 50Hz | 1,075 RPM |
| Motor Frame Material | Rolled Steel |
| HP @ 50Hz | 1/3 |
| Conduit Box Location | Interior |
| Full Load Amps @ 50Hz | 3.5 A |
Description
The U.S. Motors 6986 is a 1/3 hp condenser fan motor. This single-phase motor operates at 1,075 RPM on 208-230V AC, drawing 3.5 full load amps, and features a resilient base mounting.
