- Phase: Three
- Voltage: 230V AC
- Frequency: 60 Hz
- Horsepower: 3 hp
- Leadscrew Size: 7/8 in x 8 TPI
Specifications
| Part Number | 311450 |
| Brand | Sporlan |
| Phase | Three |
| Voltage | 230V AC |
| Frequency | 60 Hz |
| Distance Between Centers | 40 in |
| Horsepower | 3 hp |
| Overall Length | 74 in |
| Overall Width | 28 3/10 in |
| Overall Height | 50 in |
| Bed Width | 7 12/25 in |
| Gap Length | 9 1/2 in |
| Overall Depth | 68 1/2 in |
| Leadscrew Size | 7/8 in x 8 TPI |
| Item | Lathe |
| Includes | (6) Leveling Pads (Not Shown), 4-Position Carriage Stop (Pre-Installed), 6 in (150 mm) Backplate (Pre-Installed), 6 in Three Jaw Scroll Chuck (Pre-Installed), Follow Rest (Pre-Installed), Splash Guard (Pre-Installed), Steady Rest (Pre-Installed), Tool Box |
| Tailstock Taper | MT3 |
| Number of Spindle Speeds | Variable |
| Spindle Bore | 1 1/2 in |
| Number of Inch Threads | 34 |
| Max. Threads per Inch | 56 |
| Max. Spindle Speed | 2,000 RPM |
| Number of Metric Threads | 34 |
| Min. Threads per Inch | 2 |
| Max. Metric Thread | 12 mm |
| Application | Metal Turning |
| Swing In Gap | 19 1/2 |
| Min. Metric Thread | 0.5 mm |
| Swing Over Cross Slide | 9 1/16 in |
| Sound Level | 60 dB |
| Min. Spindle Speed | 40 RPM |
| Swing Over Bed | 14 in |
| Spindle Nose Type | D1-4 Camlock |
| Threads per Inch - Maximum | 56 |
| Current | 4.2 A, 8.4 A |
| Spindle Speed - Maximum | 2,000 RPM |
| Includes Taper Attachment | Taper Attachment Included |
| Maximum Cross Slide Travel | 6 1/8 in |
| Includes Collet Closer | No Collet Closer |
| Metric Thread - Minimum | 0.5 mm |
| Cross Feed - Maximum | 0.015 in/rev |
| Tailstock Spindle Travel | 6 1/8 in |
| Spindle Nose Taper | D1-4 Camlock |
| Spindle Speed - Minimum | 40 RPM |
| Longitudinal Feed - Minimum | 0.0016 in/rev |
| Digital Readout Included | Newall DP700 |
| Swing Over Gap | 19 1/2 in |
| Series | EVS-1440 |
| Maximum Carriage Travel | 35 1/2 in |
| Longitudinal Feed - Maximum | 0.046 in/rev |
| Cross Feed - Minimum | 0.0005 in/rev |
| Manufacturer Warranty | Limited |
| Threads per Inch - Minimum | 2 |
| Includes Digital Readout | Digital Readout Included |
| Maximum Compound Slide Travel | 3 1/2 in |
| Lathe Head Drive | Electronic Variable Speed |
| Metric Thread - Maximum | 12 mm |
Description
The Sporlan 311450 is a lathe for metal turning applications. It operates on 230V AC, 60 Hz, three-phase power with a 3 hp motor and features a D1-4 camlock spindle nose. The unit includes a 4-position carriage stop, 6 in three jaw scroll chuck, follow rest, steady rest, splash guard, tool box, and six leveling pads.
