- HP: 1/4
- Nameplate RPM: 1,075
- Voltage: 208-230V AC
- RPM Range: 1,001-1,100
- Voltage Compatibility: 115/208-230V AC, 200-230V AC, 208-220/440V AC, 208-230/277V AC, 208-230/440V AC, 208-230/460V AC, 208-230V AC, 208-240V AC
- Hz: 60 Hz Hz
Specifications
| Part Number | 1860H |
| Brand | U.S. Motors |
| HP | 1/4 |
| Nameplate RPM | 1,075 |
| Voltage | 208-230V AC |
| Frame | 48 |
| Shaft Dia. | 1/2 in |
| Shaft Length | 6 in |
| Overall Length | 10 5/8 in |
| Length Less Shaft | 4 5/8 in |
| Bolt Circle Dia. | 5 1/8 in |
| Body Dia. | 5 5/8 in |
| Mounting Stud Length | 3/4 in |
| Lead Length | 48 in |
| Motor Shaft Rotation | CW/CCW |
| RPM Range | 1,001-1,100 |
| Motor Sub Application | Condenser Fan |
| Motor Bearings | Ball |
| Motor Shaft Design | Flat |
| No. of Speeds | 1 |
| Voltage Compatibility | 115/208-230V AC, 200-230V AC, 208-220/440V AC, 208-230/277V AC, 208-230/440V AC, 208-230/460V AC, 208-230V AC, 208-240V AC |
| Ins. Class | F |
| Motor Mounting Position | All Angle |
| Motor Enclosure Design | Totally Enclosed Air-Over |
| Motor Service Factor | 1 |
| Capacitor Required | Yes |
| Hz | 60 Hz Hz |
| Motor Design | Capacitor-Start |
| Motor Application | HVAC/R |
| Motor Thermal Protection | Auto |
| Full Load Amps | 1.7 A A |
| Motor Mounting Type | Band/Stud |
| Phase | Single |
| Max. Ambient Temp. | 70 Degrees C |
| Item | HVAC Motor |
| Duty | Continuous |
| Weight | 12.44 lb |
| Duty Cycle | Continuous |
| Stud Quantity | 8 |
| Includes | Drain Holes Both Ends |
| Features | Extended Studs, Hubless Lead End |
| Nominal Efficiency | 65.3 % |
| Motor Frame Material | Aluminum |
| Usable @ 200V | No |
| Usable @ 208V | Yes |
Description
The U.S. Motors 1860H is a permanent split capacitor condenser fan motor rated at 1/4 HP, 1,075 RPM, and 208-230V AC. This motor operates a condenser fan in a totally enclosed air-over design and requires a capacitor for operation.
