- Voltage: 24V AC
- Ambient Temp. Range: To 140 Degrees F
- NEMA Rating: 2
- Frequency: 50/60 Hz
- Operating Temperature - Minimum: -22 Degrees F
- Operating Temperature - Maximum: 140 Degrees F
Specifications
| Part Number | VA9203-BGA-2 |
| Brand | Johnson Controls |
| Voltage | 24V AC |
| Signal Type | On-Off |
| Torque | 27 in-lb |
| Cycle Time | 75 sec |
| Ambient Temp. Range | To 140 Degrees F |
| Width | 3 1/4 in |
| Depth | 2 3/4 in |
| Height | 6 3/8 in |
| Overall Height | 6 3/8 in |
| Stroke Length | Not Rated |
| Overall Width | 3 1/4 in |
| Electrical Lead Length | 4 ft |
| Overall Depth | 2 3/4 in |
| Item | Electric Ball Valve Actuator |
| Type of Actuator | Spring Return |
| Includes | Valve Linkage |
| For Use With | VG 1000 Ball Valves |
| Power Consumption | 5 VA |
| Stroke Deg. | 90 |
| Electrical Connections | Cable |
| Application | Air Conditioning, Heating, Ventilation |
| Mounting Style | Direct Mount |
| Standards | C-Tick, CCN XAPX7, CE, CSA C22.2 No. 24-93, UL Listed, UL 60730-1:02-CAN/CSA |
| Product Type | Electric Ball Valve Actuator |
| NEMA Rating | 2 |
| Includes Electrical Leads | Electrical Leads Included |
| Stroke Degree | 95 Degrees |
| Electrical Connection Type | Cable |
| Return Action | Spring Return |
| Frequency | 50/60 Hz |
| Compatible Manufacturer Model Number | VG1241AA+923BGA, VG1241AB+923BGA, VG1241AC+923BGA, VG1241AD+923BGA, VG1241AE+923BGA, VG1241AF+923BGA, VG1241AG+923BGA, VG1241AL+923BGA, VG1241AN+923BGA, VG1241BG+923BGA, VG1241BL+923BGA, VG1241BN+923BGA, VG1241CL+923BGA, VG1241CN+923BGA, VG1241CP+923BGA |
| Number of Auxiliary Switches | 0 |
| Compatible Brand | Johnson Controls |
| Operating Temperature - Minimum | -22 Degrees F |
| Compatible Series | VG1000 |
| Operating Temperature - Maximum | 140 Degrees F |
| Control Signal | On/Off |
| Shaft Type | Integrated Shaft for Valve |
| Power Rating | 6VA |
Description
The Johnson Controls VA9203-BGA-2 is a 24V AC electric ball valve actuator with spring return. This on-off actuator opens and closes the valve, providing 27 in.-lb. of torque. It is used with VG 1000 ball valves and includes the valve linkage.
