- Voltage: 24V AC/DC
- Ambient Temp. Range: To 122 Degrees F
- Frequency: 50/60 Hz
- NEMA Rating: 2
- Operating Temperature - Minimum: 32 Degrees F
- Control Signal: Proportional
Specifications
| Part Number | VA-4233-GGC-2 |
| Brand | Johnson Controls |
| Voltage | 24V AC/DC |
| Cycle Time | 76 sec |
| Ambient Temp. Range | To 122 Degrees F |
| Power Consumption | 12 VA |
| Includes | (2) Auxiliary Switches |
| Depth | 3 19/32 in |
| Height | 6 11/32 in |
| Width | 4 3/32 in |
| Overall Width | 4 1/8 in |
| Overall Height | 6 13/16 in |
| Overall Depth | 3 5/8 in |
| Stroke Length | 7/8 in |
| Electrical Lead Length | 4 ft |
| Item | Electric Globe Valve Actuator |
| Signal Type | Proportional |
| Torque | 61 in-lb |
| For Use With | Globe Valves |
| Auxiliary Switch Type | 2 SPDT |
| Type of Actuator | Spring Return |
| Electrical Connections | Cable |
| Stroke Deg. | 29/32 |
| Standards | CSA C22.2 No. 139 Certified, File LR85083, Class 3221 02, UL 873 File E27734, CCN XAPX |
| Application | Chilled/Hot Water Control, Steam Control |
| Product Type | Electric Globe Valve Actuator |
| Compatible Series | VG7000 |
| Includes Electrical Leads | Electrical Leads Included |
| Frequency | 50/60 Hz |
| NEMA Rating | 2 |
| Return Action | Spring Return |
| Operating Temperature - Minimum | 32 Degrees F |
| Compatible Brand | Johnson Controls |
| Number of Auxiliary Switches | 2 |
| Electrical Connection Type | Cable |
| Control Signal | Proportional |
| Mounting Style | Direct Mount |
| Auxiliary Contact Form | SPDT |
| Operating Temperature - Maximum | 122 Degrees F |
| Shaft Type | Integrated Shaft for Valve |
Description
The Johnson Controls VA-4233-GGC-2 is a 24V AC/DC electric globe valve actuator with spring return. This actuator opens and closes a globe valve in response to a proportional control signal. It includes two SPDT auxiliary switches and is rated for ambient temperatures up to 122 degrees Fahrenheit.
